PMA45Q-10100-00

  • Rated 4.5 (17 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options
PMA Series Brushless Servo Motor manufactured by Pacific Scientific. This Brushless Servo Motor features a Winding of 240-480V ac, 7.4A RMS along with a 115mm motor body square Frame Size.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

PMA45Q-10100-00

  • Rated 4.5 (17 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options
PMA Series Brushless Servo Motor manufactured by Pacific Scientific. This Brushless Servo Motor features a Winding of 240-480V ac, 7.4A RMS along with a 115mm motor body square Frame Size.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a PMA45Q-10100-00 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Pacific Scientific is among the leading manufacturers of motion control components that are designed to solve modern real-industry problems. This is made possible through the customized designs of aftermarket accessories that occurs following rigorous research and continuous testing to understand the ever-changing needs. These products include servo motors, drive controllers, mains filters, and electric controllers among others. With integrated systems and careful designs, the automation accessories remain powerful, can accommodate diverse applications, are future proof, and extremely rugged. All these features come in a cost-effective manner that further place Pacific Scientific at a higher position as a reliable and reputable brand.

The PMA45Q-10100-00 servo motor is designed to solve industrial problems over a long period. However, this can only be achieved when you adhere to the technical requirements during installation as well as in operation.

To the technical details, the PMA45Q-10100-00 servo motor should be operated at an ambient temperature of 00C to 400C and when installing, the peak height should not exceed 1000 meters above the sea level. When using drive controllers, always use Pacific Scientific’s SC 900 or SCE 900. Other drives may result in incompatibility issues and affect performance adversely.

To start the electric parameters, the continuous stall torque stands at 10.2 Nm while the continuous rated torque of the PMA45Q-10100-00 servo motor is estimated to be 7.3 Nm. The peak stall torque of the unit is 21.5 Nm and the peak rated torque is also 21.5 Nm. Without load, the rated speed is 4750 revolutions per minute while with load the rated speed is 4000 revolutions per minute. The rated current at peak torque stands at 15 Amps while the estimated mass of the PMA45Q-10100-00 servo motor is 9kgs. Finally, the inertia value is 0.83kgm3.

  • PMA 45Q 10100 00
  • PMA-45Q-10100-00
  • PMA45Q 10100 00
  • PMA45Q-1O1OO-OO
  • PMA45Q1010000

PMA45Q-10100-00 Technical Specifications

Servomotor Family: PMA
Frame Size: 115mm motor body square
Stack Length: 5
Winding: 240-480V ac, 7.4A RMS
Shaft: Closed Keyway, Key Fitted, DIN42995 N (Not available PMA1)
Brake: No Brake
Connector: 6PP, 12PSO
Sensor: Resolver
Customization Code, Factory Assigned: Standard Motor
