PMA Series Brushless Servo Motor manufactured by Pacific Scientific. This Brushless Servo Motor features a Winding of 240V ac max., 2.7A RMS along with a 70mm motor body square Frame Size.

Warranty
Wake Industrial Warranty
To contact sales for pricing and lead time:

Payment Methods

Visa
Mastercard
AmEx
Wire Transfer

Shipping Methods

DHL
UPS
FedEx
Freight

Our Credentials

Cary Chamber
DUNS Registered
SAM Registered
BBB Accredited

Product Description:

The PMA line of servomotors from Kollmorgen manufacturing are built for larger tolerance, and applications requiring extra ruggedness. They are relatively cost-effective -- without sacrificing quality, and highly customizable; a common attribute of the Kollmorgen brand of servomotors.

Since the PMA21B-00100-00 is inclusive of this line of brushless AC servo motors, it is well-optimized in terms of specifications and physical construction to offer the options earlier described. To ensure strict compliance with operating specifications, each servomotor model is assigned a compatible servo drive. For the PMA21B-00100-00, it is assigned the SC902-AN-001-01 and SCE902-AN-001-01 servo drives also produced by Kollmorgen. With any of these drives, the PMA21B-00100-00 operates with an input voltage of 240V AC at maximum. Coupled with the drive, it can deliver a continuous standstill torque of 0.63Nm. Its nominal torque capacity is 0.50Nm at the rated speed of 6,050 rpm. At a maximum, this motor can run up to 9,250 rpm under no-loads operation. The maximum possible torque for this motor is 1.9Nm which can also be obtained at standstill. To achieve the maximum torque, this motor requires a current of 5.4A: which can also be considered as its maximum permissible current capacity. In terms of physical dimensions and customizations, this motor weighs 1.5kg, has a square frame of 70mm with a single stack length. Based on its ‘B’-type winding, it has a nominal stall current rating of 2.7A. This motor comes with a Smooth Shaft according to DIN42955 N, no holding brake, and a right-angle-type, standard 6 pole-power and 12 Pole Sensor (0-degree code) connector. It uses a standard alignment resolver for feedback and is an overall standard-type servomotor.

Also designed according to international standards for safety and manufacturing, this servomotor truly offers the Kollmorgen excellence.

Brake
No Brake
Connector
6PP, 12PSO
Customization Code, Factory Assigned
Standard Motor
Frame Size
70mm motor body square
Sensor
Resolver
Servomotor Family
PMA
Shaft
Smooth Shaft, DIN42955 N
Stack Length
1
Winding
240V ac max., 2.7A RMS
