The Pacific Scientific PMA11A-00100-01 is a brushless servomotor from the PMA Brushless Motors series with a continuous stall torque of 0.26 Nm and a peak torque of 1.4 Nm. It features a 55 mm motor body, smooth shaft, resolver sensor, and right-angle 6-pin power connector. The motor includes an oil seal, weighs 1.2 kg, and supports up to 240V AC winding voltage.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The PMA11A-00100-01 is a brushless servo motor produced by Pacific Scientific for the PMA Brushless Motors series. Intended for precision positioning in industrial automation, it converts electrical energy into regulated rotary movement so machine tools, conveyors, and small robotic joints can follow programmed motion profiles. Its compact form factor allows integration in equipment where space and thermal budgets are limited, and the brushless construction eliminates commutator wear, supporting rapid speed modulation without maintenance downtime.
Mechanically, the motor can sustain a continuous stall torque of 0.26 Nm, letting it hold light loads without overheating, while its peak capability rises to 1.4 Nm for short acceleration bursts. The low rotor inertia of 0.012 ×10⁻³ kg·m² promotes fast reversals with minimal overshoot. Power reaches the windings through a 6PP (6-Pin Power) connector mounted in a Right-Angle orientation so cables exit parallel to the mounting face. A smooth shaft eases coupling to precision gearheads, and the built-in oil seal keeps lubricants away from the resolver cavity. Because the unit is supplied without a brake, static holding must be managed by the drive or an external locking device.
The square housing measures 55 mm on each side, and the stack length code of 1 keeps the package short for inline installations. With a mass of 1.2 kg, it adds little moving weight to lightweight gantries. Feedback is supplied by a resolver, delivering absolute position data even in electrically noisy environments. The winding draws a nominal stall current of 1.3 ARMS and is insulated for bus voltages up to 240 V AC; these values define the thermal envelope and drive compatibility. Together, the compact geometry, light mass, and resolver feedback make the motor suitable for applications where current margins are tight but accurate servo performance is required.
Frequently Asked Questions about PMA11A-00100-01:
Q: Is there a brake installed on the PMA11A-00100-01 brushless servomotor?
A: The PMA11A-00100-01 motor does not include a brake.
Q: What type of shaft does the PMA11A-00100-01 motor have?
A: This model features a smooth shaft design for coupling purposes.
Q: What is the continuous stall torque of the PMA11A-00100-01?
A: The continuous stall torque for this motor is rated at 0.26 Nm.
Q: What sensor type is used in the PMA11A-00100-01 servomotor?
A: A resolver is used as the sensor type for feedback in this motor.
Q: What type and orientation of power connector does the PMA11A-00100-01 use?
A: The power connector on this motor is a 6PP (6-pin power) connector with right-angle orientation.
