SR3642-4982-7-56BC-CU

  • Rated 4.4 (16 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Call for Expedited Shipping and Product Condition Options

Permanent Magnet DC Motor Series manufactured by Pacific Scientific. This motor features a 56C NEMA Frame and a Current (Amps) of 2.6.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The SR3642-4982-7-56BC-CU is a continuous-duty motor from Kollmorgen with excellent performance. This motor replaces the standard wound field with permanent magnet fields. The permanent magnets have an anti-cogging property that assures you of smooth performance even when the motor is operating at a low speed. The standard operating speed of the motor is 1,750 RPM. The dynamic braking prevents demagnetization.

The DC motor has a high overcurrent capacity with 180VDC voltage rating, 0.5HP power rating, 2.6A continuous current rating and 40A peak current. The motor also features 18lb-in continuous torque, 7.6lb-in/A torque constant and 6.3lb-in inertia. The NEMA mounting style unit comes in a non-vented TENV enclosure that has a 56C frame size. It also encompasses Class H insulation. The SCR rated motor additionally houses a fused and rugged commutator, standard large sealed bearings and a polyester impregnated armature that renders electrical and mechanical integrity. The brush springs are fitted with field-replaceable brushes and render constant force apart from having a long life.

This permanent magnet DC motor has an overall diameter of 6.5 inches. The motor features four equally spaced 3/8-16 UNC-2B mounting holes. The knockout holes in the unit have diameters of 0.88 inches and 0.62 inches. The device is CSA Certified, UL Recognized and CE Marked. The motor is lighter, faster and occupies lesser space than wound field motors. It encompasses a gasket style conduit box that acts as a large wiring compartment and helps in terminating the motor very easily. The company’s motor is used in almost all applications in a wide range of industrial sectors where there is no compromise to high quality and high performance. A few applications of the continuous-duty motor are defense & aerospace, medical imaging, food & beverage processing, pharmaceutical manufacturing, in vitro diagnostics & laboratory automation and medical imaging.

  • SR3642 4982 7 56BC CU
  • SR36424982756BCCU

SR3642-4982-7-56BC-CU Technical Specifications

Product Code: FGS2438
Configuration (facing p age): 1
NEMA Frame: 56C
Enclosure: TENV
Current (Amps): 2.6
Torque (lb-in.): 18
Current (Peak/A): 40
Torque Constant (lb-in./A): 7.6
Resistance (Ohms): 3.3
Inertia (lb-in.): 6.3
