105-072001-01
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 1-2 Days
The Pacific Scientific 105-072001-01 card, part of the 105 Motion Control Cards series, features DIN rail mounting and an IP20 enclosure rating. It operates with a coil voltage of 24V DC and includes 3 Normally Open contacts. The card's mechanical life reaches 10 million operations, with dimensions of 45x85x100 mm (WxHxD).
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The 105-072001-01 motion control card from Pacific Scientific lands right in the mix for jobs that need reliable switching and protection in industrial setups. Designed as part of the 105 Motion Control Cards group, it comes set for DIN rail mounting, and the body holds up well since the enclosure protection is IP20. Overall size on this card measures out to 45 mm x 85 mm x 100 mm, and the weight works well for quick add-and-remove swaps when panels need to change out or expand. Electrical gear on busy lines needs order, and this model delivers three Normally Open (3NO) contacts built so electrical paths can snap on or off in the pattern that’s programmed up.
A standout here is the coil voltage of 24V DC, something standard enough that it slides right into most control racks without a lot of digging for special supplies. Both current and lifespan numbers give this card some substance—25A rated current is enough for plenty of actuator and relay circuits, and mechanical operations top out at 10 million cycles, while electrical cycles reach 1 million. Inside, there’s also a mix of auxiliary contacts—1NO and 1NC, so extra feedback or safety signals get tied into systems easily. The screw terminal style keeps connections grounded and tight, a good fit for places where vibrations or constant maintenance re-tightening push other types loose.
Not every rack or field cabinet holds the same temperatures, which is where the -25°C to +55°C operating spread comes into play. Whether mounted up high near cold air vents or tucked near heated surfaces, the spec makes fitment less stressful. Use cases show up in spots like assembly automation or conveyor junctions, where multi-contact switching or precise relay work keeps downtime down.
Frequently Asked Questions about 105-072001-01:
Q: What coil voltage does the 105-072001-01 card operate at?
A: The 105-072001-01 card operates at a coil voltage of 24V DC.
Q: What type of mounting is supported by the Pacific Scientific 105-072001-01 card?
A: The Pacific Scientific 105-072001-01 card supports DIN rail mounting.
Q: What is the enclosure rating of the 105-072001-01 motion control card?
A: The enclosure rating of the 105-072001-01 motion control card is IP20.
Q: What is the current rating of the 105-072001-01 motion control card?
A: The 105-072001-01 motion control card has a current rating of 25A.
Q: What is the operating temperature range for the Pacific Scientific 105-072001-01 card?
A: The Pacific Scientific 105-072001-01 card operates within a temperature range of -25°C to +55°C.
