MIV0404-1-B5 Okuma
Wake Industrial LLC is not an authorized distributor of this product.
MPN: 1006-2232-0239038
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Okuma MIV0404-1-B5 is an inverter unit from the MIV Servo Drives series designed for use with BL and PREX motors. It supports two axes, offers an applicable capacity of 4.0 kW per axis, and uses a DC bus input of 300 VDC with 24 VDC control power. This unit features a dual 7-segment LED status display, measures 380 by 100 by 325 mm, and weighs 7.8 kilograms.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MIV0404-1-B5 inverter unit is manufactured by Okuma and belongs to the MIV Servo Drives series. As an inverter module for multi-axis CNC systems, it supplies controlled three-phase power to synchronous or induction servomotors and coordinates feedback from the machine position loop. Integrated into an Okuma THINC control, the unit exchanges data with the master drive and linked encoders so that each axis receives the torque and speed commands needed for precise machining and automated material handling. This control arrangement allows the system to correct axis motion in real time during contouring, positioning, and synchronized machine movement. It is intended for coordinated motion where consistent response from multiple axes is required across repeated production cycles.
The unit is rated for an applicable capacity of 4.0 kW × 4.0 kW for its dual inverter outputs. It supports 2 programmable axes for coordinated motion within one enclosure. Power for the main switching stage is supplied by a shared DC link at 300 VDC, while logic circuits and relay coils use a separate 24 VDC control supply so status monitoring can remain active when the main bus is off. Gating signals and current feedback are handled on the dedicated ICB1 inverter control board, which manages PWM operation and protective response. This layout keeps the control and power sections separated for stable drive operation.
The housing measures 380 × 100 × 325 mm, which helps the unit fit beside other servo amplifiers in a compact control cabinet. Its mass is 7.8 kg, which helps limit mounting load on the panel and eases handling during installation. An MFP1 CARD plugs into the front slot to store parameter data and the control ROM type 5. Operating states, alarms, and axis codes are shown on a Dual 7-Segment LED display, and the front connectors route Servo, Encoder, and Converter links to BL or PREX motors without extra breakout panels. Front access to these connections also helps keep wiring organized inside densely packed CNC cabinets.
Frequently Asked Questions about MIV0404-1-B5:
Q: How many axes can the MIV0404-1-B5 servo drive control?
A: The MIV0404-1-B5 drive supports two axes for servo control operations.
Q: What motor types can be used with the MIV0404-1-B5 drive?
A: This drive is compatible with both BL motors and PREX motors.
Q: What is the required DC bus input voltage for the MIV0404-1-B5?
A: A DC bus input of 300 VDC is required for the MIV0404-1-B5 unit.
Q: What control power voltage does the MIV0404-1-B5 require?
A: For control operations, this drive uses a 24 VDC power input.
Q: What type of status display does the MIV0404-1-B5 inverter have?
A: The unit features a dual 7-segment LED for displaying status information.
