MF-P2M2S
Wake Industrial LLC is not an authorized distributor of this product.
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships in 3 Days
The MF-P2M2S module, part of Okuma's FUB Servo Modules series, is a versatile I/O Board designed for 24 VDC systems. It operates within a temperature range of -10°C to 60°C and features multiple I/O ports for connectivity. This module adheres to standard Okuma card dimensions and weighs approximately 1.5 Kg.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Okuma MF-P2M2S is a Multifunctional I/O board for Okuma CNC systems. It improves information processing and control within the system, allowing it to function more effectively and reliably. Okuma, a well-known brand in industrial automation, made this board so that it works perfectly with CNC environments. This way, users can get high-performance results in a wide range of industrial settings.
The MF-P2M2S I/O board uses DC24V ± 10% to power its 16 photo-coupler input ports. These ports can handle up to 9mA of ON current and up to 3.5mA of OFF current. A protective circuit with a protective current range of 0.5A to 1.6A is built to keep the main line safe. Both an analog and a digital filter are used in the input filter to get rid of waves that are 5ms or less. The board has 16 MOSFET output ports on the output side. These ports are powered by DC24V ±10% and can handle a contact output current of 1.7A. There is a current monitoring circuit for each output port that keeps it safe. The protective current range is from 1.8A to 2.5A.
The MF-P2M2S I/O board is small yet durable measuring 30 mm in height and 250 mm in length and weighing 1.35 lbs (0.61 kg). It is designed to fit into the second or later slot of a multifunction unit, with the address defined by the slot position. To prevent overheating and guarantee dependable performance, a current-detecting circuit is integrated into every output port. Thanks to its cutting-edge features, this board is an excellent choice for improving the functionality and longevity of CNC systems, which in turn leads to more efficient and accurate manufacturing procedures.
Frequently Asked Questions about MF-P2M2S:
Q: How do Okuma MF-P2M2S filter pulses effectively?
A: The board filters pulses under 5ms using both analog and digital filters. This ensures accurate data transmission and prevents errors.
Q: What is the benefit of overcurrent protection in Okuma MF-P2M2S?
A: Overcurrent protection prevents potential damage from excessive currents. This protects both the inputs and outputs, enhancing system reliability.
Q: Does Okuma MF-P2M2S support DC24V power supply?
A: Yes, the board operates on a DC24V ±10% power supply. This stable power ensures reliable performance in diverse environments.
Q: Why does Okuma MF-P2M2S include MOSFET outputs?
A: MOSFET outputs provide efficient switching and control capabilities. These outputs help manage high currents with minimal energy loss.
Q: Do Okuma MF-P2M2S inputs have current limits?
A: Yes, the minimum ON current is 9mA, and the maximum OFF current is 3.5mA. These limits ensure precise signal processing.
