The Okuma BL-D75A is an axis drive unit in the BL Servo Drives series and is compatible with 5020 and 7000 controls. It includes protection features such as VR-LOSS monitoring for control power, high-speed no-fuse breaker for grounding, and FOL detection for heat sink overheating. The unit uses dynamic braking as a stop method during alarms and features an armature-winding thermostat for overload sensing.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The BL-D75A axis drive unit is produced by Okuma within the BL Servo Drives series. It acts as the interface between the machine’s DC bus and a single servo motor, translating command signals from the numerical control into regulated current and voltage. In industrial automation, this function keeps each feed axis on the programmed path while machining, probing, or indexing. It also helps the control system maintain stable motion when the axis changes speed, direction, or cutting load.
This drive communicates directly with 5020 and 7000 controls, so parameter blocks, alarms, and diagnostics are exchanged without additional converters. Control-power integrity is supervised by VR-LOSS Monitoring; if the logic supply collapses, the drive disables its output before corrupt data can reach the motor. A dedicated ground path is enforced through a High-Speed No-Fuse Breaker, which disconnects the unit when line-to-ground faults are detected faster than mechanical fuses can respond. Thermal loading of the base plate is watched by FOL Overheat Detection; this sensor initiates a shutdown when the heat sink reaches a preset temperature. For DC-link undervoltage, the BL-D75A trips when the bus falls below 200 VDC, preventing incomplete commutation and loss of torque.
On the current side, the amplifier issues an alarm once demand rises above 120% of its current limit, protecting drive transistors and motor windings. Continuous overload is tracked by an Armature-Winding Thermostat located in the motor circuit, so rising copper temperature automatically feeds back to the drive. Regenerative energy is supervised by OH Overheat Detection, ensuring the built-in resistor does not exceed its thermal capacity during fast decelerations. When any of these faults occur, the stop sequence is enforced through a Dynamic Brake, which dissipates kinetic energy internally and holds the axis until the CNC cancels the alarm. This controlled stopping action reduces the chance of uncontrolled coasting after a protection event.
Frequently Asked Questions about BL-D75A:
Q: Which control systems are supported by the BL-D75A drive?
A: The BL-D75A drive is compatible with 5020 and 7000 control systems for integrated automation setups.
Q: What type of control power protection does the BL-D75A provide?
A: This model includes VR-LOSS monitoring for control power protection.
Q: How does the BL-D75A implement grounding protection?
A: A high-speed no-fuse breaker is used for grounding protection in the BL-D75A.
Q: What stop method is utilized on the BL-D75A drive during an alarm?
A: The BL-D75A is equipped with dynamic braking as its stop method when an alarm is triggered.
Q: What heat sink protection does the BL-D75A feature?
A: FOL overheat detection is used to protect the heat sink in the BL-D75A drive.
