STF5332-3748-61-56BC

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Stock: Call for Quote
  • Call for Expedited Shipping and Product Condition Options
The STF5332-3748-61-56BC is manufactured by Kollmorgen as part of the STF Washdown Motor- Food Grade Series. It features a continuous current of 4.6 A and a continuous torque of 36.0 lb-in. As well as a peak current of 36.0 A and a torque constant of 8.00 lb-in/A. Certified by the Bakery Industry Sanitation Standards Committee and contains a 17550 RPM.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

STF5332-3748-61-56BC

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Stock: Call for Quote
  • Call for Expedited Shipping and Product Condition Options
The STF5332-3748-61-56BC is manufactured by Kollmorgen as part of the STF Washdown Motor- Food Grade Series. It features a continuous current of 4.6 A and a continuous torque of 36.0 lb-in. As well as a peak current of 36.0 A and a torque constant of 8.00 lb-in/A. Certified by the Bakery Industry Sanitation Standards Committee and contains a 17550 RPM.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a STF5332-3748-61-56BC to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The STF5332-3748-61-56BC DC motor is one of the several STF series motors from Kollmorgen. The SCR rated motor comes with a non-removable welded base made of stainless steel. The unit has a power rating of 1HP. It is equipped with large and standard sealed bearings. The environmentally protected product comes with wash-down duty specifications. The device is UL Recognized and BISSC Certified. The motor comprises a protection category of IP 65. It is housed in a TENV enclosure with a NEMA 56C frame and a NEMA C face. The STF5332-3748-61-56BC motor can be shipped to any address worldwide through our logistics partners like UPS or FedEx.

The DC motor has a voltage rating of 180V. This product comes with permanent magnets that produce light, efficient and small magnetic fields. The device is equipped with long-life brush springs that generate constant force and feature field-replaceable brushes. It operates at a low speed of 1,750RPM. The unit comes fitted with a gasketed conduit box. The motor features a continuous torque rating of 36lb-in and a continuous current rating of 4.6A. This standard device comes with Class H insulation. The product has a polyester impregnated armature. This armature offers the motor the required mechanical and electrical integrity.

A rugged commutator is fused into the motor. The anti-cog property of the magnets ensures the smooth running of the device even when it operates at a low speed. The unit has a length of 13.30 inches. It has a peak current rating of 36A. The motor shaft has a diameter of 0.625 inches. The STF5332-3748-61-56BC motor encompasses four equally spaced mounting holes. The device features a resistance of 2.4 Ohms and an inductance of 32mH. It complies with NEMA MG1-1.26.5 waterproof specification. This DC motor is available with one-year warranty support.

  • STF53323748-6156BC

STF5332-3748-61-56BC Technical Specifications

Continuous Current : 4.6 A
Continuous Torque: 36.0 lb-in
Inductance : 32.00 mH
Inertia: 22.4 lb-in
Peak Current: 36.0 A
Resistance: 2.4
Torque Constant: 8.00 lb-in/A
