STF3758-5150-61-56BC

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Stock: Call for Quote
  • Call for Expedited Shipping and Product Condition Options
The STF3758-5150-61-56BC is manufactured by Kollmorgen as part of the STF Washdown Motor- Food Grade Series. It features a continuous current of 7.3 A and a continuous torque of 27.0 lb-in. As well as a peak current of 126.0 A and a torque constant of 4.05 lb-in/A. Certified by the Bakery Industry Sanitation Standards Committee and contains a 17550 RPM.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

STF3758-5150-61-56BC

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Stock: Call for Quote
  • Call for Expedited Shipping and Product Condition Options
The STF3758-5150-61-56BC is manufactured by Kollmorgen as part of the STF Washdown Motor- Food Grade Series. It features a continuous current of 7.3 A and a continuous torque of 27.0 lb-in. As well as a peak current of 126.0 A and a torque constant of 4.05 lb-in/A. Certified by the Bakery Industry Sanitation Standards Committee and contains a 17550 RPM.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a STF3758-5150-61-56BC to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The STF3758-5150-61-56BC is a DC motor with an SCR rating from Kollmorgen. It features permanent magnets. The magnetic fields generated by these magnets make this product lighter, smaller and more efficient than wound field motors. The device comes in a TENV enclosure with a NEMA 56C frame and NEMA C face. The frame encompasses a removable base. The unit has a power rating of 3/4HP. It is BISSC Certified and UL Recognized. The motor has a peak current rating of 126A and a torque constant of 4.05lb-in/A. The food-grade motor comes along with a warranty period of one year.

The motor is compliant with NEMA MG1-1.26.5 waterproof designation. It has a protection category of IP 65. It features a rugged design and combines value with performance. This device houses a gasketed conduit box that serves as a large wiring compartment to make the termination easy. The patented magnets have an anti-cog property that allows the product to operate smoothly at low speed. The unit has a speed of 1,750RPM. This motor has a voltage rating of 90V and inertia of 8.7lb-in. It has a length of 15.2 inches and a weight of 41 pounds.

The standard washdown duty motor is fitted with standard and large sealed bearings. The DC motor comes with a fused and rugged commutator. It features Class H insulation. The device has a high overcurrent capacity as well as dynamic braking functionality without demagnetization. This unit comprises a continuous current rating of 7.3A and a continuous torque rating of 27lb-in. The product comes fitted with a polyester impregnated armature and constant force brush springs. It has an inductance of 3.5mH and a resistance of 0.72 Ohms. The environment-friendly STF3758-5150-61-56BC motor can be shipped anywhere across the globe.

  • STF37585150-6156BC

STF3758-5150-61-56BC Technical Specifications

Continuous Current : 7.3 A
Continuous Torque: 27.0 lb-in
Inductance : 3.50 mH
Inertia: 8.7 lb-in
Peak Current: 126.0 A
Resistance: 0.72
Torque Constant: 4.05 lb-in/A
