The Kollmorgen SL3407-00000 is part of the SL3000 AC Motor Drives series and provides a horsepower rating of 7.5 HP with an input and output current of 11.0 Amps. The drive features an overload capacity of 150% for 60 seconds and a starting torque of 150% at 3 Hz. Its dimensions are 12.35 inches in height, 9.50 inches in width, and 7.06 inches in depth.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The SL3407-00000 is an AC motor drive manufactured by Kollmorgen for the SL3000 AC Motor Drives series. Designed for panel installation, this drive receives fixed three-phase input power and produces a variable-frequency output so plant controllers can regulate motor speed in real time. By managing acceleration, deceleration, and steady-state operation, it supports precise tension, flow, or positioning tasks in automated conveyors, mixers, and pump stations. Its compact enclosure measures 12.35 in high, 9.50 in wide, and 7.06 in deep, which helps it fit standard cabinets while still leaving room for airflow and wiring.
The drive supports motors up to 7.5 HP at base speed. To reach this level, it draws a mains current of 11.0 A and places an apparent power demand of 8.7 kVA on the supply. The displacement between voltage and current is held to a power factor of 0.88, which helps reduce reactive loading and transformer heating. Momentary load spikes are handled by an overload reserve of 150 % for 60 s, allowing the inverter to provide additional torque without immediate protective trips. These electrical limits are coordinated with the internal switching behavior so semiconductor temperatures remain within the rated range.
The controller can deliver a peak phase current of 16.5 A rms during acceleration, and its open-loop start routine generates 150 % torque at 3 Hz to help overcome static load inertia. The braking resistor is permitted to absorb energy for 5 s every 2 min, and its internal network develops 40% torque during each stop. Steady operation at a carrier frequency of 6 kHz causes heat dissipation of 175 W at 6 kHz, a value used when sizing enclosure ventilation. Line protection is provided by a 20 A fuse on the supply feed, and full ratings remain available up to a mounting altitude of 3300 ft.
Frequently Asked Questions about SL3407-00000:
Q: What is the horsepower rating of the SL3407-00000 AC motor drive?
A: The SL3407-00000 from Kollmorgen is rated for 7.5 horsepower output.
Q: What is the peak current capacity of the SL3407-00000 drive?
A: This model has a peak current (rms) rating of 16.5 A.
Q: What overload capacity does the SL3407-00000 drive provide?
A: The SL3407-00000 can deliver 150% of its rated output for up to 60 seconds.
Q: What starting torque is available with the SL3407-00000 at 3 Hz?
A: It achieves a starting torque of 150% at 3 Hz for efficient motor startup.
Q: What is the maximum altitude rating for the SL3407-00000 AC motor drive?
A: This drive is suitable for installation at altitudes up to 3300 feet.
