The Kollmorgen S60600-NA is a servo drive from the S600 Servo Drives series with a current rating of 6A rms and a peak output current of 12A rms. It features IP20 enclosure protection and supports a voltage range of 230 to 480 volts. The unit measures 275 mm in height and 265 mm in depth, with a maximum ambient temperature of 45°C.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Kollmorgen’s S60600-NA belongs to the S600 Servo Drives series and is listed by the manufacturer as an S600 servo drive that regulates torque, velocity, and position of matched servomotors in automated cells and machine tools. By converting three-phase mains power into controlled output phases, the unit supplies the feedback-driven current loops needed for precise motion control. It is intended for closed-loop motion tasks in which motor feedback is used to correct speed and position errors during operation. That behavior supports coordinated motion where steady torque delivery and accurate axis response are required. Its compact housing supports installation in enclosed industrial control cabinets.
The drive operates from a line span of 230 to 480 V and can deliver a continuous phase current of 6 A rms, with transient events handled by a peak capability of 12 A rms. For onboard logic, its auxiliary circuit requires 24 VDC at up to 3 A, and the internal brake transistor can source current for dynamic braking functions. Cabinet ingress protection is rated at IP20, so the unit must be installed inside an enclosure. Idle operation dissipates 15 W, rising to 60 W at rated current, and the incoming section withstands a residual voltage drop of 5 V without tripping. With a rated installed load of 4 kVA, wiring and fusing must match feeder capacity. The drive’s input reference measures 20 kΩ to analog ground, and the connected motor must have coil inductance between 7.5 mH and 40 mH so the current loop remains stable under PWM excitation.
Mechanical clearance is aided by a height of 275 mm and a depth of 265 mm, dimensions that allow side-by-side mounting on DIN rail or backplate. Continuous operation is specified up to 45 °C, and higher ambient temperatures require derating to protect the power semiconductors. The unit accepts no expansion modules, so its operation stays limited to the base drive functions. This form factor works with compact cabinet layouts and leaves space for thermal clearance and cable routing.
Frequently Asked Questions about S60600-NA:
Q: What input voltage range does the Kollmorgen S60600-NA servo drive support?
A: The S60600-NA servo drive supports an input voltage range from 230 to 480V, allowing for flexible installation with compatible power supplies.
Q: What is the continuous current rating of the S60600-NA servo drive?
A: This servo drive can deliver a continuous current of 6A rms to connected motors during normal operation.
Q: What enclosure protection rating does the S60600-NA servo drive have?
A: The S60600-NA is protected to the IP20 standard, providing basic protection against solid objects but not water.
Q: What is the maximum brake output current of the Kollmorgen S60600-NA?
A: This model can provide up to 2 A brake output current for reliable holding brake operation.
Q: What is the rated installed load capacity for the S60600-NA servo drive?
A: The rated installed load for the S60600-NA servo drive is 4 kVA.
