The Kollmorgen S20660-CNS is an S200 Servo Drive with a continuous output power of 2000 W at 240 Vac and a peak output power of 6000 VA. It offers a current rating of 6 ARMS continuous and 18 ARMS peak and supports 120/240 VAC input. The drive measures 64 mm wide, 131.6 mm deep, and 175 mm high, and weighs 0.89 kg.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The S20660-CNS servo drive is produced by Kollmorgen and is part of the S200 Servo Drives series. As a compact, panel-mounted unit, it conditions three-phase mains power and delivers controlled DC bus energy to matched Kollmorgen servo motors. In industrial automation, the device functions as an axis amplifier that interprets motion commands from a controller and modulates current so that attached motors follow programmed position, velocity, and torque profiles. Integration is simplified through its built-in CANopen position node mode.
During normal operation, the drive sustains a 2000 W continuous output when fed by a three-phase 240 VAC source. It delivers phase current of 6 ARMS continuous and 18 ARMS peak, with each peak held for 3.0 s. The DC link runs at 320 VDC nominal and suppresses regeneration at 397 VDC. A 120/240 VAC universal mains rating allows installation in panels with either single-phase or three-phase service, while the logic circuits draw only 10 W. Motor windings from 1.5 mH to 75 mH are accepted without series chokes. Feedback options include the SynqNet EnDat 2.1 card, the sine-encoder card, and an SFD/Comcoder CAN module, and all units also recognize SFD/Hall signals.
The power stage can supply a 6000 VA short-term apparent output, while an internal resistor absorbs up to 20 J of regenerated energy before external braking is needed. Switching devices operate at 16 kHz, which helps reduce output ripple that could excite mechanical resonances. The housing measures 175 mm high, 64.0 mm wide, and 131.6 mm deep, and the assembly weighs 0.89 kg. Because the drive appears on CANopen as a position node, axis setup and status reporting can be handled over the same network used for motion commands. The supported motor inductance range allows use with motors that have different electrical time constants.
Frequently Asked Questions about S20660-CNS:
Q: What is the continuous output power of the S20660-CNS servo drive?
A: The S20660-CNS has a continuous output power rating of 2000 W when supplied with 240 VAC three-phase.
Q: What are the continuous and peak current ratings for the S20660-CNS?
A: This servo drive offers a continuous current rating of 6 ARMS and a peak current rating of 18 ARMS.
Q: Which feedback types does the S20660-CNS servo drive support?
A: The S20660-CNS supports SFD/Halls feedback on all units, with additional options for Sine encoder and EnDat 2.1 via SynqNet option cards.
Q: What functionality mode does the S20660-CNS provide?
A: The S20660-CNS features a Position Node with CANOpen interface for its primary functionality mode.
Q: What is the supported motor inductance range for the S20660-CNS servo drive?
A: This model can handle motors with inductance ranging from 1.5 mH to 75 mH.
