The Kollmorgen MSM115-34-404-M-0KA-240N is part of the MSM Brushless Servo Motors series and has a continuous torque of 3.8 Nm and a peak torque of 12 Nm. This servo motor features a multiturn high resolution feedback type and a rated speed of 4000 rpm. It operates at a voltage class of 460 V, has a pole count of 6, and a net weight of 6.6 kg.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MSM115-34-404-M-0KA-240N is a brushless servo motor built by Kollmorgen within the MSM Brushless Servo Motors series. As a compact rotary actuator, it converts drive current into precisely metered torque and speed for indexing tables, pick-and-place arms, or other tightly controlled motion axes in industrial automation. Six poles and a multi-turn high-resolution feedback device let the controller close position loops with high granularity even after power cycling.
Its continuous torque capability of 3.8 Nm is the load the shaft can sustain indefinitely without excessive heating. When short bursts are needed, the motor delivers up to 12 Nm of peak torque, providing headroom for acceleration or overcoming static friction. Rated mechanical speed is 4000 rpm, so the rotor can turn four thousand times per minute while maintaining servo accuracy. To reach these operating points, the drive may supply as much as 15.6 A Peak, while the locked-rotor stall current is 4.5 A peak. A 460 V voltage-class winding aligns with common DC-bus levels in multi-axis cabinets, and the electromagnetic conversion factor is 0.95 Nm/A, simplifying current-based torque calculations.
Dynamic response is influenced by the rotor’s mass moment; at 0.00057 kg-m², it resists acceleration only slightly, supporting fast cycle commands. The winding inductance of 32.0 mH filters current ripple, while the 8.4 ohm resistance sets copper losses that must be modeled thermally. Back EMF is characterized by a voltage constant of 115 V/KRPM, allowing predictive regeneration estimates during deceleration. Installation details include an M6 × 1.0 mm shaft thread with a 16 mm depth for secure attachment of couplings or pulleys. Overall mass is 6.6 kg, light enough for gantry end-effectors yet heavy enough to damp vibration.
Frequently Asked Questions about MSM115-34-404-M-0KA-240N:
Q: What is the continuous torque rating of the MSM115-34-404-M-0KA-240N servo motor?
A: This servo motor provides a continuous torque output of 3.8 Nm for sustained load applications.
Q: What type of feedback system is included in the MSM115-34-404-M-0KA-240N?
A: The MSM115-34-404-M-0KA-240N features multiturn high resolution feedback for precise position monitoring.
Q: What is the maximum current the MSM115-34-404-M-0KA-240N can handle?
A: The peak current for this model is 15.6 A, enabling brief high-power operation.
Q: What is the rated rotational speed of the MSM115-34-404-M-0KA-240N?
A: This servo motor operates with a rated speed of 4000 rpm.
Q: What are the shaft thread specifications of the MSM115-34-404-M-0KA-240N?
A: The shaft of this servo motor uses an M6 x 1.0 mm thread with a depth of 16 mm.
