Product Description

The M-107-B-33-B3 GOLDLINE servomotor from Kollmorgen is a medium inertia motor in the M series. The servomotor has a compact size and weighs 5 KG. The UL Recognized device makes use of resolver feedback and features a 230VAC voltage rating. The servomotor works with the manufacturer’s SERVOSTAR SR06 digital amplifier for high performance and also offers various other options. The amplifier comes with a seven-segment LED display and an error history log for diagnostics.

The servomotor has 2.2Nm continuous torque and 4.2Nm peak torque. It is equipped with a rear shaft extension, an inbuilt thermostat, a frameless resolver, IP65 sealing, and Class H insulation. The unit also offers support for including an encoder adapter, a brush tachometer, fail-safe brakes, and inline planetary gearheads externally. The motor features rear earth magnets that are made of neodymium-iron-boron combination that encompass high energy. The amplifier features fully digital control loops and velocity loop bandwidths of maximum 170Hz as well as 125µs commutation update rate and 500 µs velocity loop update rate. It offers protection against foldback, feedback loss, overspeed, and output phase to phase short circuit. The amplifier has an encoder equivalent output.

The brushless servomotor has 7,500RPM maximum speed and 2HP continuous power rating. It has 4.2Nm peak torque when it is stalled. The motor has 0.765 x 10⁴ kg-m² motor inertia. The digital amplifier has a 6A continuous current rating and must be stored between -20°C and 70°C. It features CCW and CW end travel limit inputs. The amplifier supports field tunable digital compensation apart from three selectable digital compensation modes. Its MOTIONLINK software helps in tuning programming through an RS-232 serial interface. The servomotor can be shipped to any address across the world through our trusted delivery network. It comes with a one-year warranty period.
