Product Description:

The LSM63-12-604-M-0KA-240N is a brushless servo motor produced by Kollmorgen within the LSM Brushless Servo Motors series. It converts electrical energy into controlled rotary motion for positioning tasks in automated assembly lines, packaging machinery, and semiconductor tools. Integrated electronic commutation and feedback enable the drive to maintain commanded speed and torque, making the motor a compact actuator for applications that require repeatable motion profiles and rapid cycle times. Its compact frame suits installations where space is limited on custom stages and gantries.

The motor delivers a rated speed of 6000 rpm, allowing it to track rapid command changes without step loss. Under continuous duty, it supplies 12 in-lb of torque, giving actuators consistent rotational force during steady motion. The three-phase stator is wound for 460 V operation, so it works directly with standard industrial drives used on North American power systems. The mechanical interface uses a 63 mm bolt-hole circle that aligns with compact IEC flanges. Control wiring is simplified by a single 17-pin circular connector that carries power and feedback leads, and the resolver output inside that connector is provided as differential sine/cosine waveforms for smooth closed-loop interpolation.

The motor uses multiturn high-resolution feedback to provide absolute position information across multiple revolutions, which eliminates homing after power loss. Surface temperature may rise to 125 °C during peak loading, so cabinet airflow or external heat sinks must keep the frame below this limit. At operating speed, the shaft can withstand a radial side load of 23 kg, supporting small pulleys or couplings without additional bearings. The motor uses a keyway shaft for slip-free torque transfer, but it does not include a shaft seal or an external blower, so placement in dusty or high-humidity areas requires careful attention.
