The Kollmorgen E22NRFT-LNN-NS-00 is a NEMA 23 hybrid stepper motor from the E Hybrid Stepper Motors series. It features a 2.25 inch frame diameter, a laminated rotor, and uses SIGMAX construction. The motor offers connection options for parallel, series, or unipolar modes and includes 8 lead wires with a regular leadwire style.
Internal Product Review
The E22NRFT-LNN-NS-00 is a Kollmorgen hybrid stepper motor with a NEMA 23 frame and a 1.8-degree step angle. SIGMAX construction and a laminated rotor give the motor a precise, well-controlled feel in indexing and positioning service. A 200-step-per-revolution design with winding optimized for maximum torque at low speed makes the motor an excellent choice for steady, accurate motion.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The E22NRFT-LNN-NS-00 is a hybrid stepper motor produced by Kollmorgen as part of the E Hybrid Stepper Motors series. Supplied in a two-phase configuration, it occupies the NEMA 23 class footprint found on many mid-range axes. By advancing the shaft in fixed increments commanded by a drive, the motor gives machine builders a straightforward way to position indexing tables, light gantries, and labeling heads without adding encoders or other feedback devices. Its open-loop operating style also suits repeatable motion tasks that benefit from simple control architecture.
Each electrical pulse shifts the rotor by 1.8 degrees, so a complete turn is divided into 200 discrete positions and in-position deviation stays within the ±1.5% step-accuracy band. A laminated rotor, SIGMAX construction, and two internal stacks emphasize torque at low speed, while the smooth, single-ended shaft mates directly with couplers. That arrangement helps the motor produce useful holding and running torque without increasing the mounting footprint. The housing measures 2.25 in across the frame and matches the NEMA 23 mounting face. Electrical terminations emerge as an 8-lead harness that can be wired in parallel, series, or unipolar mode through the regular lead-wire connection style. No shaft seal is fitted, which reduces drag during low-speed torque delivery.
Windings carry Class B, 130 °C insulation. Insulation resistance is 100 Megohms, and dielectric strength reaches 340 Vdc to the frame. Permissible ambient air spans -20 °C to +40 °C, covering unheated startups as well as normal enclosure temperatures. These electrical limits help the motor tolerate the insulation stress commonly found in cabinet-mounted drive systems. The operating range also suits indoor automation equipment that runs in moderate ambient conditions for extended periods.
