Product Description

Kollmorgen is a renowned manufacturer and supplier of the latest motion control devices. The company produces a wide range of synchronous servo motors, brake resistors, and industrial PCs.

The DBL5N02200-0R2-00K-S40 model is highly recommended by our international clients due to its maintenance-free operation and high functional stability. The model is a synchronous servo motor and belongs to the family of the DBL series. The DBL5 synchronous servo motor comes with a 142 mm flange size that allows installation in horizontal (IM B5), vertical with the shaft facing downward (IM V1), and vertical with shaft facing upward (IM V3) mounting positions. The current and position of the servo motor are controlled by the servo amplifier by using 2-pole resolver feedback. The shaft with keyways is installed in this motor to deliver the continuous output power of 5.34/6.03 kW while operating at the rated power voltage of 400 – 480 V with ±10% augmentation. The DBL5 synchronous servo motor consumes the maximum current of 63.7 A, and the winding inductance of the motor is 10.5 mH. The servo motor can operate at the maximum ambient temperature of +45 degree Celsius, without derating under the maximum relative humidity of 95%. The motor comes with permanent magnets to provide high constant torque under extreme working conditions.

The model DBL5N02200-0R2-00K-S40 comes with a B-side power connector and the overall weight of the DBL5 motor is 16.2 kg. The motor can run at the maximum speed of 3600 rpm at a 480 V power source. The thermal time constant for this synchronous motor is 75 minutes. The motor is manufactured according to Canadian and American standards. The unit performs communication electronically by the servo amplifier. The motor comes under insulation class F and a thermostat is attached for controlling the temperature of the motor. Get this DBL5 synchronous servo motor DBL5N02200-0R2-00K-S40 from Wake Industrial along with the DBL instruction manual in your native language.
