The Kollmorgen DBL3M00190-BR2-000-S40 is a brushless servo motor that is part of the DBL Synchronous Servomotors series and features a flange size of 75 mm and a standard length design. It is equipped with a resolver feedback type, a smooth shaft, and comes with a holding brake offering a holding torque of 2.5 Nm. The motor supports a protection class of IP54, uses connectors for connection, and operates at ambient temperatures from 5 to 40 degrees Celsius.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DBL3M00190-BR2-000-S40 is a brushless servo motor built by Kollmorgen and supplied within the DBL Synchronous Servomotors series. Designed for closed-loop axis control, the unit converts drive current into precise torque for positioning tables, pick-and-place heads, and similar motion axes on production lines. It employs permanent-magnet rotor technology and integrates an electromechanical holding brake so loads remain fixed when power is removed. By combining a compact frame with a standard-length stator iron, the motor fits into equipment where space and dynamic response are equally important.
In operation, the motor is protected to IP54, so limited dust and splashed water will not interfere with the windings or bearings. Its circular mounting interface uses a 75 mm flange that lets the housing bolt directly to gearboxes or machine plates. The integrated brake resists up to 2.5 Nm of load torque, maintaining axis position during stops. Rotor position is returned to the drive through a resolver, allowing feedback that is inherently resistant to electrical noise. Continuous service is allowed from 5 to +40 °C, and the insulation system tolerates ambient moisture up to 95% relative humidity.
Performance characteristics are influenced by the stator geometry, which uses a 2-pole layout for low inertia and regular flux transitions. Power reaches the rotor through plug-in connectors, and the motor uses a smooth shaft to transfer motion to couplings without key slots. The selected medium-speed winding variant balances torque and speed when driven by a standard inverter. Other details include the standard-length housing, an orientation angled toward the B-side that directs the connector set away from neighboring axes, and a protective contact inside the feedback connector that maintains proper grounding under vibration.
Frequently Asked Questions about DBL3M00190-BR2-000-S40:
Q: Does the DBL3M00190-BR2-000-S40 motor come with a holding brake and what is its holding torque?
A: This model is equipped with a holding brake that provides 2.5 Nm of holding torque.
Q: What feedback type is utilized on the DBL3M00190-BR2-000-S40 servomotor?
A: The DBL3M00190-BR2-000-S40 motor uses a resolver as its feedback device.
Q: What is the protection class rating for the DBL3M00190-BR2-000-S40?
A: This servomotor has a protection class of IP54 for limited dust and water ingress.
Q: What kind of shaft design does the DBL3M00190-BR2-000-S40 feature?
A: The shaft design for this motor is a smooth shaft, offering compatibility for various coupling methods.
Q: What is the flange size of the DBL3M00190-BR2-000-S40 motor?
A: This servomotor has a flange size of 75 mm, making it suitable for compact installation requirements.
