DBL3M00190-B3M-000-S40 Kollmorgen
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
The Kollmorgen DBL3M00190-B3M-000-S40 is a brushless servo motor in the DBL Synchronous Servomotors series with a 75 mm flange size and smooth shaft design. It features an encoder feedback type, multiturn capability, and includes a holding brake with a torque of 2.5 Nm. This standard length motor supports connectors for connection and has an IP54 protection rating.
Internal Product Review
The DBL3M00190-B3M-000-S40 is a Kollmorgen brushless servo motor that feels well suited for precise, dependable motion control. Multiturn encoder feedback gives the motor a strong technical advantage in positioning tasks. A 2.5 Nm holding brake and IP54 protection make this unit especially appealing for secure operation in industrial service.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DBL3M00190-B3M-000-S40 is a brushless servo motor manufactured by Kollmorgen as part of the DBL Synchronous Servomotors series. Supplied in a standard length, it functions as a compact drive element for packaging, indexing, and pick-and-place axes where fast response and consistent torque are required. Its role in automation is to convert commanded current from the drive into precise rotary motion for position-controlled machinery.
Electrical and feedback terminations are carried out through connectors, which simplify cable connection without disturbing cabinet wiring. The motor seats against a machine face through a square flange that measures 75 mm, providing compatibility with common mounting patterns while keeping the overall footprint small. Its housing carries the IP54 protection class, so airborne dust and water spray do not reach the internal windings during normal plant washdowns. A normally engaged brake delivers 2.5 Nm of holding torque to lock the shaft whenever supply voltage is removed, which helps secure vertical or suspended loads. Rotor position is captured by an incremental encoder, giving the drive a clear reference for commutation and closed-loop speed regulation. The power connector is angled toward the B-side to ease cable routing in confined panels.
The motor is rated for continuous duty from 5 to +40 °C, allowing it to share an enclosure with control electronics. Operation is also permitted at up to 95% relative humidity without condensation, supporting use in damp process areas. Power is transmitted through a smooth shaft, which simplifies clamp coupling and avoids keyway backlash. The feedback assembly is identified as Multiturn, indicating support for multi-revolution position tracking. The winding is the medium-speed variant, combining adequate torque with manageable heat rise during extended motion sequences.
