The BA3648-4650-9-56BC is manufactured by Kollmorgen as part of the BA and BAF Low Voltage Motor Series. It features an HP of 43894and a voltage of 24 V. It holds a continuous current of 28.2 A and a torque constant of 1.02 lb-in. Made to undergo a resistance of 0.06 ohms and hold an inductance of 0.22 mH.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

BA3648-4650-9-56BC

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • Call for Expedited Shipping and Product Condition Options
The BA3648-4650-9-56BC is manufactured by Kollmorgen as part of the BA and BAF Low Voltage Motor Series. It features an HP of 43894and a voltage of 24 V. It holds a continuous current of 28.2 A and a torque constant of 1.02 lb-in. Made to undergo a resistance of 0.06 ohms and hold an inductance of 0.22 mH.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a BA3648-4650-9-56BC to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The BA3648-4650-9-56BC motor features a low voltage rating. This motor is one of the BA series of motors manufactured by Kollmorgen. It encompasses a NEMA C face with a removable base. The device features a 24V rating and a 3/4HP power rating. The unit is intended for use with batteries and other low voltage supplies. The DC motor has a maximum speed limit of 1,750RPM and is equipped with permanent magnets. The device is characterized by high efficiency. It is housed in a TENV enclosure. The knockout holes have diameters of 0.62 inches and 0.88 inches. The motor is available with a one-year warranty from Wake Industrial.

The motor shaft has a diameter of 0.625 inches. The product is UL Recognized and has a Class H insulation. The device can be made to function directly using a battery without any motion control interface for constant speed. This unit has a continuous current rating of 28.2A, a factory assigned peak current rating, and an inertia of 7.1lb-in. It features a NEMA 56C frame. The permanent magnet fields of the motor are lighter, smaller, and more efficient than that of the manufacturer’s wound-field motors. The motor encompasses constant force and long-life brush springs that house field-replaceable brushes.

The motor has a continuous torque rating of 27lb-in and torque constant of 1.02lb-in/A. The device can be fitted with a low voltage motor control for adjustable speeds. This product features a resistance of 0.06 Ohms and an inductance of 0.22mH. It comprises large sealed bearings and a fused as well as a rugged commutator. The unit has an overall length of 12.10 inches and weighs 29lbs. The manufacturer’s motors are used in several industries for a wide range of applications. The BA3648-4650-9-56BC motor can be delivered to any address around the world with a warranty for one year.

BA3648-4650-9-56BC Documents

  • BA36484650956-BC
  • BA36484650956BC
  • BA-36484650956-BC

BA3648-4650-9-56BC Technical Specifications

Continuous Current: 28.2 A
Continuous Torque : 27.0 lb-in
HP: 3/4
Inductance : 0.22 mH
Resistance: 0.06 ohms
Torque Constant : 1.02 lb-in
Voltage: 24 V
