The AKM42G-BKCN2-01 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 20.4 Nm. The AKM series also featured a max rated force of 6000 and max rated power of 1.73 kW.

AKM42G-BKCN2-01

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKM42G-BKCN2-01 Is manufactured by Kollmorgen and features a max BUS of 640 and max Tp of 20.4 Nm. The AKM series also featured a max rated force of 6000 and max rated power of 1.73 kW.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a AKM42G-BKCN2-01 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The AKM42G-BKCN2-01 falls under the AKM series of Kollmorgen servo motors. Like other motors in this series it is designed to operate in conjunction with SERVOSTAR servo amplifiers for positioning tasks in a wide array of applications such as industrial robots, machine tools, and packaging and textile machines. It features a mains voltage of 480 VAC, 3.53Nm and 4.80A standstill torque and current respectively. The rated speed is 6000min-1, rated torque is 2.35Nm, and the rated power is capped at 1.48kW. It weighs 3.39kg and has a static friction torque of 0.026Nm.

The AKM42G-BKCN2-01 features a NEMA flange of size 48mm, a G winding type, and a shaft with open keyway. It has a customized option which features shaft seal. The feedback is a ComCoder with 2048PPR while the connectors are angular and feature an IP 65 protection class. It comes in a brushless motor thanks to the servo amplifier that offers electrical commutation. It features an electrically isolated thermistor that through temperature sensors in the stator windings, monitors the motors temperature. This, together with class F insulation material protect it from thermal overload while allowing to withstand high temperatures.

Use couplings or collets that are backlash-free and frictionally-locking. Ensure that they assume the correct alignment to eliminate vibration during operation that might damage the coupling and bearings. Avoid axial loading to maintain the predetermined motor life. Since it is precision equipment, handle it with care. The AKM42G-BKCN2-01 shaft and flange are vulnerable to damage during storage and assembly. Avoid brute force or blows to mitigate damage to the shaft and bearings. Get this Kollmorgen servo motor from Wake Industrial.

  • AKM-42G-BKCN2-01
  • AKM42G-BKCN2-O1

AKM42G-BKCN2-01 Technical Specifications

Frame Size: AKM4
Frame Size:
Max BUS (VDC): 640
Max Rated N: 6000
Max Rated Power at Max BUS: 1.73 kW
Max Stall Tc: 6.0 Nm
Max Tp: 20.4 Nm
Stack Length: 2
