Product Description:

The AKM63G-ANCNR-00 servo motor belongs to the AKM Synchronous Servo Motors series produced by Kollmorgen. It is intended for industrial automation systems that require accurate velocity and position control, such as indexing tables, delta robots, or traverse axes in web handling. The unit’s medium rotor length index of 3 offers a balance between response time and continuous torque, while its standard customization level keeps mechanical and electrical details consistent across the family for easy integration.

The motor housing carries a 138 mm frame dimension, establishing the bolt circle and shaft height for installation in IEC-sized machinery. Power and feedback exit through 2 SpeedTec Ready connectors, a keyed design that supports quick connection and helps prevent mis-mating. Motion is transferred by a smooth shaft, so couplings or pulleys can mount without the stress concentrations associated with a keyway. Because the unit is supplied without a brake, holding torque during power-off must be provided by the drive or by external mechanics. Rotor position is measured by a resolver, giving noise-immune sine-cosine signals suited for high-temperature environments.

An IEC flange with accuracy N aligns the stator to gearboxes or frames without shims, which helps maintain concentricity and low vibration. The resolver delivers 2-pole feedback resolution, matching servo drives that expect one electrical cycle per mechanical turn, and its architecture provides single-turn inductive feedback for commutation and position tracking within one mechanical revolution. The stator uses the G winding designation, which gives electrical characteristics suited for use with medium-voltage AKD drives. The feedback hardware occupies the Size 10/15/21 envelope, allowing compact rear dimensions while maintaining thermal pathways for continuous duty.
