Product Description:

The AKM54L-ANCNC-00 belongs to the AKM Synchronous Servo Motors series produced by Kollmorgen. As a brushless servo unit, it converts drive controller commands into precise rotary motion for positioning tables, feeders, and light machine axes on automated lines. The compact frame and integrated encoder make it suitable for equipment where space is limited yet dynamic response is required. That combination supports accurate speed regulation and repeatable positioning in compact machine sections.

This model is supplied without a brake, so holding torque must be provided by the drive or an external lock when power is removed. Power and feedback reach the motor through 2 SpeedTec Ready connectors, and the quarter-turn couplers help keep cable attachment straightforward in tightly packed installations. The feedback carrier is the SFD protocol, allowing direct plug-in to Kollmorgen drives that read rotor angle in real time. A frame dimension of 108 mm matches the square mating surface used for Kollmorgen size 5 housings. The shaft is a smooth shaft, which eliminates key stress points and simplifies hub mounting for couplings or pulleys. These features are supplied under the standard customization level for this model.

The encoder section delivers position data through four differential channels, and its measurement path is a single turn, inductive design that resists dust and oil. This arrangement supports stable signal transmission between the motor and compatible drive electronics. The motor uses rotor length index 4, which extends the active iron to raise continuous torque without changing the flange outline. The mounting face follows IEC with accuracy N, so concentricity and bolt-circle tolerances match common European machinery frames. Internal copper uses winding designation L, a layout chosen for medium bus voltages and moderate inertia loads, and the feedback head is built on size 10/15/21 components that match the four-line signal format used across the AKM family.
