Product Description:

The AKM52M-ACC22-00 is produced by Kollmorgen within the AKM Synchronous Servo Motors series. This brushless rotary motor delivers programmable position, velocity, and torque for automated assembly cells, packaging stations, and material-handling axes. Its compact electromagnetic design supports fast acceleration, which helps motion controllers execute coordinated multi-axis profiles with responsive speed changes and precise shaft control. That makes it useful on indexing, transfer, and synchronization tasks where repeatable motion is required throughout a production cycle.

A factory-installed 24 V holding brake locks the shaft when power is removed, helping maintain axis position on vertical loads or during emergency stops. Power and feedback exit through 2 SpeedTec Ready connectors; these bayonet fittings permit tool-free coupling and help prevent miswiring in crowded panels. Position data are generated by a Comcoder that supplies 2048 lines/rev of incremental information, giving fine command resolution for closed-loop motion. The sensing element is EPC 15T, which matches the encoder electrical format used with compatible Kollmorgen drives. All components are contained in a frame with a diameter of 108 mm, so the motor mounts directly to gearheads or brackets that follow the corresponding IEC size code. This connection layout also keeps motor power and signal paths organized at the housing.

Complementing the incremental channels, the encoder uses single turn optical feedback, which avoids multi-turn gearsets and simplifies axis referencing after startup. Mounting accuracy is governed by the flange coded as IEC with accuracy N, supporting concentricity and face runout tolerances that suit precision reducers. The stainless-steel shaft includes a keyway, enabling rigid couplings or pulleys to transmit torque without slippage. The motor uses winding designation M, which balances current draw and speed capability for compatible AKD drives. Rotor length index 2 keeps inertia suited to moderate load ratios, and the customization level is standard so the motor follows the regular mechanical and electrical configuration for this model. These features support accurate coupling alignment and stable feedback behavior during repeated start-stop duty.
