Product Description:

The AKM44J-EKCNR-01 is a synchronous servo motor produced by Kollmorgen within the AKM Synchronous Servo Motors series. It converts controlled current from a matched drive into precise rotary motion for indexing tables, pick-and-place heads, and light-duty conveyors. This operating role suits machinery that depends on fast cycle rates and accurate position control.

During short motion bursts, the motor can deliver a peak torque of 20.4 Nm while drawing a peak phase current of 35.2 A. At zero speed, it sustains a standstill torque of 6.00 Nm from a continuous current of 8.80 A, which helps define amplifier sizing under thermal limits. Ten poles, winding designation J, passive cooling, and a brake-free design support responsive operation, while two SpeedTec ready connectors carry power and resolver signals.

The mechanical interface tolerates a radial load of 450 N and an axial load of 180 N at 3000 rpm, supporting pulley or pinion attachments without reducing bearing life. Drive designers use a winding inductance of 3.8 mH and a phase resistance of 0.94 Ω when setting current loops and estimating thermal dissipation. The resolver uses a size 10/15/21 package with two electrical poles, providing single-turn absolute feedback that remains dependable in electrically noisy environments.

Wake Industrial stocks this model and can arrange same-day shipping for time-critical repairs. Each purchase is backed by a 1-year warranty. Quotes remain valid for 30 days, and the chat tool available on the website can be used for questions about type codes or fault codes during routine maintenance planning.
