The AKM44E-ACC2DB-00 is a synchronous servo motor manufactured by Kollmorgen as part of the AKM Synchronous Servo Motors series. It features a 24V holding brake and comes with 2 SpeedTec Ready connectors. The motor also uses an EnDAT 2.1 encoder with multi-turn optical feedback and has a frame dimension of 84mm with an IEC flange and keyway shaft detail.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The AKM44E-ACC2DB-00 belongs to the AKM Synchronous Servo Motors series produced by Kollmorgen. As a brushless servo motor, it is intended for precise position and velocity control in industrial automation, pairing with Kollmorgen drives to move packaging axes, pick-and-place gantries, or indexing tables with repeatable accuracy. The motor is suited to applications that need stable speed regulation, repeatable positioning, and quick response to changing load conditions. Its brushless design supports smooth torque delivery and reduces routine wear in systems that run frequent start-and-stop motion cycles.
For controlled stopping and power-off holding, the motor carries a 24 V holding brake that engages automatically when drive power is removed. Electrical terminations are provided through two SpeedTec Ready connectors, and the SpeedTec bayonet interface shortens connection time while maintaining positive locking under vibration. Rotor position is reported through an EnDAT 2.1 encoder, and its incremental track provides 512/2048 lines per revolution, giving the drive high-resolution counts after interpolation. Absolute position is retained by multi-turn optical feedback, so the axis powers up with position knowledge over many shaft turns. This combination supports accurate closed-loop control and helps the drive track startup position and fine motion changes during operation.
The mechanical package uses a keyway shaft profile to transmit torque to pulleys or couplings without slip. An 84 mm frame keeps the motor compact while providing the cross-section needed for heat transfer, and the front face uses an IEC flange with accuracy N for direct mounting on compatible machines or gearboxes. Internal laminations extend to rotor length index 4, which increases magnetic volume for higher continuous torque. The compact housing helps the motor fit into dense machine layouts where mounting space is limited. Winding code e balances speed constant and current demand so the motor can be matched cleanly to Kollmorgen drive options in medium-voltage motion platforms.
Frequently Asked Questions about AKM44E-ACC2DB-00:
Q: Does the AKM44E-ACC2DB-00 servo motor include a braking system?
A: The AKM44E-ACC2DB-00 model comes equipped with a 24V holding brake for secure load retention when power is off.
Q: What type of connector arrangement does the AKM44E-ACC2DB-00 use?
A: This servo motor uses two SpeedTec ready connectors for electrical connections, facilitating quick and reliable setup.
Q: What feedback system is used in the AKM44E-ACC2DB-00 motor?
A: The feedback system on this motor is an EnDAT 2.1 encoder, delivering high-precision feedback control.
Q: What is the shaft configuration of the AKM44E-ACC2DB-00?
A: The shaft on this model features a keyway, allowing secure mechanical coupling with compatible components.
Q: What flange configuration does the AKM44E-ACC2DB-00 feature?
A: This servo motor has a flange configuration that meets IEC standards with accuracy class N.
