Product Description:

The AKM41H-CCCN2-00 is a brushless servo motor manufactured by Kollmorgen within the AKM Synchronous Servo Motors series. As a compact rotary actuator, it converts controlled electrical power from a matched drive into precise mechanical motion for indexing tables, pick-and-place axes, and packaging machinery in industrial automation. This frame size sits in the middle of the series and offers a practical balance between torque output and installation space.

This unit is supplied without a brake, so position holding during power loss must be provided by the drive or by an external clamp. The motor uses 2 SpeedTec Ready connectors for power and feedback, allowing fast tool-free cabling through keyed bayonet fittings. The housing uses an 84 mm frame, which matches the mounting footprint used for size 084 machines. It also uses Alternative Flange Variant C, which shifts the pilot and threaded-hole pattern relative to the standard face when space around the mounting surface is limited. Output torque is transmitted through a keyway on the shaft, allowing pulleys or couplings to lock securely without relying on set screws alone.

The integrated Comcoder provides incremental position data at 2048 lines/rev, which equals 8192 quadrature counts per mechanical revolution for the servo loop. Its encoder is a single-turn optical device, so multi-turn position tracking must be handled externally when that function is required. The sensing element uses the EPC 15T format, allowing compatibility with AKM models that share the same code. The motor also uses winding designation H, a coil variant selected for nominal voltage and speed targets in 230 VAC systems. With rotor length index 1 and a standard customization level, the motor has a baseline configuration suited to applications that need moderate inertia and quick acceleration.
