Product Description:

The AKM33H-ANDNCA-00 servo motor is produced by Kollmorgen within the AKM Synchronous Servo Motors series. It converts commanded current from a matched drive into regulated rotation for pick-and-place axes, indexing tables, and coordinated packaging stations in industrial automation. By combining high-energy magnets with concentrated windings, the motor delivers strong torque density while keeping mass low, so compact motion axes can maintain fast response in restricted spaces.

The unit is supplied without a brake, so any power-off holding torque must be provided externally. Output power is delivered through a smooth shaft, which simplifies coupling where low backlash is required. The square housing uses a 70 mm frame dimension, allowing installation in IEC-sized mountings. Power and feedback share a single 1 i-tec Hybrid or SpeedTec Ready Hybrid connector, which reduces cable bulk and helps conserve cabinet space. Position data is generated by the integrated SFD3 feedback system, and its digital signal path provides fast absolute angle information for tight servo loops.

The mechanical interface uses an IEC flange with accuracy N, helping maintain concentric alignment for gears or belt pulleys without extra shimming. Magnetic stack geometry follows Rotor length index 3, which balances continuous torque capability with moderate thermal rise in mid-range duty cycles. Absolute position is delivered by single-turn inductive feedback, which avoids cycle counting and offers good resistance to shock. Electrical characteristics follow winding designation H, so the selected drive parameters must match the motor’s voltage constant and resistance values. The rear-mounted hybrid connector keeps the side surfaces clear, which helps when nearby coolant or pneumatic lines must run close to the motor body.
