Product Description:

The AKM33H-ANCNDA-00 is a brushless synchronous servo motor produced by Kollmorgen for the AKM Synchronous Servo Motors series. It is intended for automated packaging lines, pick-and-place gantries, and inspection stations. In these applications, it converts commanded current into tightly regulated torque, allowing axes to maintain precise speed and position under varying loads during repeated motion cycles.

This model is supplied without a brake, so holding force must be provided by the drive or an external clamp when power is removed. Two electrical terminations are provided as 2 SpeedTec Ready connectors, and the keyed quarter-turn couplers help limit wiring errors during cable attachment. Rotor position and diagnostic data are carried through a digital EnDAT 2.1 encoder, eliminating the need for analog sine-cosine channels. The optical disc provides 512/2048 lines/rev, and interpolation in the drive supports fine resolution when correcting small position errors. The housing remains slim because of the 70 mm frame dimension, allowing the motor to fit into tight mechanical pockets on multi-axis machines.

The sensing hardware uses the ECN1113/1313 feedback type, which integrates an emitter, detector, and a single glass codewheel in a compact assembly. This arrangement supports single-turn optical scanning, so absolute position is available after each power-up without batteries or gearsets. Rigid mounting is provided by an IEC flange with accuracy N, and the specified concentricity helps keep misalignment forces off the smooth shaft. The stator uses a H winding, so voltage, resistance, and thermal characteristics match Kollmorgen AKD and S700 drives set to the corresponding code. The rotor uses length index 3 to balance inertia against peak torque, and the smooth shaft mates with clamp or keyless couplings for backlash-free motion.
