Product Description:

The AKM24F-ENMN2-00 is an AC synchronous servo motor developed by Kollmorgen for precision positioning tasks in industrial automation. It belongs to the AKM Synchronous Servo Motors series, a family used with digital drives for coordinated motion axes. This motor converts controlled electrical input into rotary movement with tight speed and torque regulation, making it suitable for indexing tables, pick-and-place heads, and packaging machinery. It is intended for coordinated motion axes that require accurate response during repeated start-stop cycles. The compact housing and standardized mechanical interface let the unit fit into servo stages with minimal adaptation.

Its frame measures 58 mm across the mounting face, which sets the bolt pattern and shaft height for compact servo mechanisms. The motor is supplied without a brake, so holding force at standstill must come from drive torque or an external clamp. A smooth shaft allows coupler or pulley attachment without keyways, which can help reduce vibration in high-speed cycles. The motor uses rotor length index 4, which corresponds to the magnetic stack length for this frame size. The stator uses winding designation F, which matches the resistance, inductance, and voltage constant used by compatible Kollmorgen drive models.

Position feedback is delivered through a Comcoder, which combines incremental tracks and commutation channels for a one-cable connection to the drive. Its native resolution of 2048 lines/rev supplies 8192 post-quadrature counts, supporting fine velocity regulation. The sensor is a single-turn optical device, so absolute position is retained only within one revolution and multi-turn tracking must be handled by the control system. The identification string EPC 15T designates the encoder electronics and pinout for compatibility with standard AKD and SERVOSTAR amplifiers.
