AKM24C-EFCNR-00 Kollmorgen
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
The Kollmorgen AKM24C-EFCNR-00 is part of the AKM Synchronous Servo Motors series and features a 58mm frame dimension with rotor length index 4. It is equipped with a resolver feedback system, providing single turn inductive feedback with 2 poles, and comes without a brake. The servo motor uses two SpeedTec Ready connectors for connections and is built to standard customization level.
Internal Product Review
The AKM24C-EFCNR-00 is a Kollmorgen AKM synchronous servo motor with a standard configuration. A resolver feedback system with single-turn inductive feedback supports dependable position feedback and smooth commissioning. Dual SpeedTec-ready connectors add practical installation value for well-executed servo builds.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The AKM24C-EFCNR-00 servo motor is produced by Kollmorgen for use in closed-loop motion axes. It belongs to the AKM Synchronous Servo Motors series and is intended for compact permanent-magnet applications that require precise position and speed control in automated machinery. In these systems, the motor converts drive commands into controlled rotary motion for indexing, transfer, and synchronized positioning tasks. Its standard geometry allows it to pair with Kollmorgen AKD and other compatible servo drives in packaging, pick-and-place, and material-forming equipment.
The motor body spans 58 mm across the mounting flange, which supports installation where space is limited while still providing room for the stator. That size helps the motor fit dense machine layouts without requiring a larger mounting footprint. Power and feedback pass through 2 SpeedTec Ready connectors that use bayonet locking for quick and secure cable connection. Rotor position is detected by a resolver, providing analog angle data that remains stable under vibration and temperature changes. The feedback system uses 2 poles, meaning the resolver senses two electrical cycles per mechanical revolution. It also uses single-turn inductive feedback, which reports absolute position over 360 degrees without batteries or mechanical gear reduction. The motor has a rotor length index 4, indicating the fourth length variant and a longer active iron section than shorter versions.
For holding and emergency-stop situations, the motor is supplied without a brake, so external holding must be provided when power is removed. When the axis must remain fixed at standstill, a mechanical clamp or continuous drive torque must hold the load. The electromagnetic circuit uses winding designation C, which matches the motor to drives that supply the voltage and current associated with that winding. The unit is supplied at the standard customization level, so the housing materials, shaft details, and seal options follow Kollmorgen's baseline configuration.
