Product Description:

The AKM22E-ANBNR-00 is a synchronous servo motor manufactured by Kollmorgen and supplied within the AKM Synchronous Servo Motors series. Serving as a compact rotary actuator, it is intended for use in industrial automation where tightly controlled position, speed, and torque are required on pick-and-place heads, indexing tables, or light conveyor zones. By integrating with a servo drive, this motor transforms regulated electrical power into repeatable mechanical rotation that supports closed-loop motion profiles in manufacturing or packaging equipment.

This model is delivered without a brake, so any load must be held by the drive or by external locking methods when power is removed. The frame width measures 58 mm, allowing installation in machines with limited cross-section while still providing adequate thermal mass for continuous duty. A smooth shaft simplifies coupling to timing pulleys or bellows couplings and avoids stress concentrations found in keyed designs. Electrical terminations are concentrated in 2 SpeedTec Ready connectors, which support quick bayonet engagement and reduce wiring time on the assembly line. Rotor position is monitored by a built-in resolver, and the front flange follows IEC accuracy grade N for precise alignment with gearheads or mounting plates.

The resolver uses 2 poles, meaning a single electrical cycle occurs per mechanical revolution. It provides single-turn inductive position data for commutation and feedback during operation. Winding designation e identifies a coil set optimized for mid-range bus voltages, while the feedback hardware follows the non-contact Size 10/15/21 envelope so it fits inside the SpeedTec connector shell. The motor is supplied at the manufacturer's standard customization level and uses rotor length index 2 to balance inertia against peak torque for moderate-load axes.
