Product Description:

The AKM11C-AKCNC-00 is a compact synchronous servo motor produced by Kollmorgen and assigned to the AKM Synchronous Servo Motors series. Designed as a drive element for industrial automation, the unit converts regulated current from a matching servo amplifier into tightly controlled rotary motion for precise positioning and speed control. Its compact size makes it suitable for space-restricted axes in pick-and-place robots, electronic assembly tables, and miniature conveyors where high accuracy and low inertia are required. This format also suits short-cycle motion tasks that need repeatable starts and stops in limited installation space.

The motor body follows an IEC flange with accuracy N pattern, allowing direct attachment to metric gearheads without adapter plates. A frame dimension of 40 mm pairs with rotor length index 1 to keep mass low while maintaining the active stack length needed for servo operation. Position feedback is delivered through an SFD encoder supplying 4 lines of differential signals. The encoder uses a single-turn inductive design, so absolute position is retained over one mechanical revolution without batteries. The rotor uses winding code C for balanced torque production and thermal loading. Because the unit is supplied without a brake, an external holding mechanism is required when static load holding is necessary.

Electrical and mechanical interfacing is completed through 2 SpeedTec Ready connectors that lock with a quarter turn and seal properly when mated. The feedback package is housed in Size 10/15/21, which matches Kollmorgen’s low-profile connector shells and keeps the connection area compact. Power is transmitted by an open keyway shaft, simplifying coupling to pulleys or compact gear stages. The standard customization level includes the AKM family thermal sensors, and the connector arrangement keeps power and feedback routing organized within the small motor envelope.
