The AKD-P02407-NBAN-0000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 16000 Watts and a rated supply voltage of 240/480 V. As well as, Rated output current of 24 A and a peak output current of 48 A. AKD drives offer the greatest output in a compact body.

AKD-P02407-NBAN-0000

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
The AKD-P02407-NBAN-0000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 16000 Watts and a rated supply voltage of 240/480 V. As well as, Rated output current of 24 A and a peak output current of 48 A. AKD drives offer the greatest output in a compact body.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a AKD-P02407-NBAN-0000 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Kollmorgen AKD series of servo drives houses Ethernet-based drives that are easy to interface with other devices on the factory floor. Designed around flexibility and ease of use, these drives provide plug-and-play commissioning allowing for a seamless and instant access to everything in a machine. AKD series drives deliver a high performance, industry-leading power levels, and communication options. For easy programming and set-up, these drives support the Kollmorgen WorkBench graphical user interface. Whether the standard processing power is not enough, Kollmorgen AKD drives support options cards to boost processing power and the number of inputs and outputs to be connected.

The AKD-P02407-NBAN-0000 is a Kollmorgen servo drive in the AKD series. The drive is designed to be operated with an input voltage of 480 Volts AC. Where the voltage available is 240 Volts AC, the AKD-P02407-NBAN-0000 has the VBUS.HALFVOLT parameter to set the input voltage at half the standard operating voltage. Apart from AC voltage, this servo drive can be powered by an DC voltage via the direct DC input terminals. This enables the AKD-P02407-NBAN-0000 to adapt to a wide range of industrial environments. Note that the nominal level of direct current voltage applied on the drive must be compatible with the drive’s voltage fault levels.

The Kollmorgen AKD-P02407-NBAN-0000 fault levels are rated at 380 Volts DC for the undervoltage level and 840 Volts DC for the over voltage level. To minimize the set-up time when connecting a motor, the drive automatically detects any feedback devices together with motor parameters. The AKD-P02407-NBAN-0000 automatically fills-in the values for current, commutation and velocity loop gains. The AKD-P02407-NBAN-0000 has a current rating of 24 ARMS and supports analog connectivity options.

  • AKDP02407-NBAN-0000
  • AKD-PO24O7-NBAN-OOOO

AKD-P02407-NBAN-0000 Technical Specifications

Control Logic, Supply Voltage: 24 V
Control Logic, Supply Voltage:
Current Loop Bandwidth Max.: 2-3 kHz
Drive Continous Output Power: 16000 Watts
Peak Output Current: 48 A
Rated Output Current: 24 A
Rated Supply Voltage: 240/480 V
Velocity Loop Bandwidth Max.: 0-600 Hz
