Product Description:

The AKD-P01207-NAAN-0000 servo drive is manufactured by Kollmorgen and belongs to the AKD Servo Drives series. It is an AC-powered motion controller intended to regulate brushless motors in automated machinery. Inside a control cabinet, the device converts three-phase mains power into controlled current sequences so motion axes can follow commanded trajectories with tight velocity and position accuracy. It can synchronize tooling, conveyors, or pick-and-place heads without relying on mechanical gearing, which helps support flexible motion profiles across different machine sections.

The drive has a nominal output of 12 Arms, allowing continuous current delivery to medium-frame servomotors, while momentary peaks up to 30 Arms for five seconds provide extra torque during acceleration or load disturbances. It handles apparent power of 7.65 kVA, so the incoming electrical supply must be sized for that load. Acceptable mains are three-phase 240 / 480 Vac, and an internal rectifier automatically configures itself to the selected voltage range. The Position Indexer mode executes stand-alone motion sequences and can receive target values through its Analog command interface when a higher-level PLC is not present. The Standard USA customization uses North American defaults for line frequency and terminology. The unit has no expansion slots (rev 7), so no auxiliary I/O or safety boards are installed.

Within the AKD Servo Drive family, this model uses a standard-width frame and weighs 5.3 kg, so it fits vertical panel mounting without additional reinforcement. The internal heat sink is proportioned for full S1 duty at rated current, and the narrow housing leaves clearance for adjacent drives on a DIN rail. That spacing helps preserve airflow around the enclosure while keeping terminal areas easier to route. Its weight also limits mechanical stress on the mounting panel during normal operation.
