Product Description:

The AKD-B02406-NBSQ-0000 is a closed-loop servo drive manufactured by Kollmorgen in the AKD Servo Drives series. It acts as the regulated power stage between a motion controller and the motor, converting incoming electrical power into controlled output for accurate speed and position control. In packaging lines, pick-and-place axes, and test rigs, the unit supplies three-phase motor power with the response needed for repeatable motion. Its closed-loop design allows the axis to correct motion errors in real time instead of operating like an open-loop inverter.

The drive accepts 120 / 240 Vac 1~/3~, allowing connection to either single-phase 120 V supplies or three-phase 240 V sources without tap changes. Under continuous duty, it delivers 24 Arms, which suits medium servo loads during sustained operation. For short acceleration demands, the output can rise to 48 Arms for five seconds so the motor has additional current available during rapid speed changes. The input section is sized for 7.6 kVA of continuous apparent power, which sets the supply demand seen by the facility source. Motion commands and synchronization travel over SynqNet, giving deterministic communication across coordinated multi-axis systems.

The drive uses the Standard USA customization, which suits North American installation practices. Its Base version includes the core torque, velocity, and position control functions, and no hardware extension is included on revision 8 and later units. Installation is aided by a width of 70 mm and a mass of 3.7 kg, which help when several drives must fit side by side in a control cabinet. The narrow housing supports dense panel layouts, while the relatively low weight reduces load on mounting hardware. This is useful where cabinet space is limited and multiple axes are grouped in one enclosure.
