Product Description:

The AKD-M01207-MCEC-0000 is a programmable servo drive controller supplied by Kollmorgen as part of the AKD-PDMM Programmable Drives series. It combines power conversion, axis control, and embedded programming in a single housing for industrial automation. Within a machine cabinet, the module delivers regulated three-phase output to servomotors while executing user logic, which removes the need for a separate PLC in multi-axis packaging, material-handling, or converting systems. Its integrated design shortens wiring runs, reduces system latency, and keeps motion control functions close to the power stage for faster response during coordinated moves.

At 400 VAC, the drive supplies a continuous phase current of 12 Arms, equal to 4.2 kVA of steady output. One analog input accepts a ±10 V reference, and the front panel includes 13 opto-isolated digital inputs plus 6 digital outputs for limit switches, sensors, and actuator interlocks. Power enters on a three-phase 240/400/480 VAC bus. The housing is 185 mm deep, 99 mm wide, and 256 mm high, so it fits shallow panels while still allowing airflow around the enclosure. Internal shunt circuitry dissipates regenerative energy, and an integral cooling channel directs heat toward the top of the housing to keep components within their operating temperature range.

A single 800 MHz single-core processor coordinates as many as 64 axes through the deterministic EtherCAT motion network, allowing cam tables and gearing calculations to run inside the drive. For brief accelerations, the output stage can deliver 30 Arms, translating to a peak power capability of 10.4 kVA before returning to its continuous operating range. This peak region is protected by hardware current limits and electronic supervision to safeguard magnetic components and connected motors. Field devices can be routed to the local I/O, which helps reduce the need for additional interface modules and keeps related signals near the control point.
