195N0061 Danfoss
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: VLT2822PT2B20STR0DBF00A00C0
The Danfoss 195N0061 is a low voltage drive in the VLT 2800 Low Voltage Drives series. It has a power rating of 2.2 kW, supports 3-phase input at 200-240V AC, and delivers up to 3.0 horsepower. The drive features a built-in display, an IP20 protection rating, and a bookstyle enclosure.
Internal Product Review
The 195N0061 is a Danfoss VLT 2800 low voltage drive configured for process duty with a 2.2 kW power rating. A 200-240V AC input and 3-phase design make the unit well suited for consistent industrial drive control. The bookstyle enclosure with IP20 protection supports clean cabinet integration and dependable service.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The 195N0061 is an AC variable-frequency drive manufactured by Danfoss for the VLT 2800 Low Voltage Drives series. Within an automation cell, it regulates the speed of three-phase induction motors so process equipment can operate at the rate required by flow, pressure, or conveyor setpoints. Its compact housing supports installation in decentralized panels that power pumps, fans, mixers, and other continuous-duty process equipment. The drive converts fixed-frequency incoming power into an adjustable motor output, allowing connected machinery to respond to changing operating demands without mechanical speed-control components.
The drive accepts a supply of 200–240 V AC from a three-phase network and delivers an adjustable output of up to 2.2 kW, which corresponds to a motor output of 3.0 HP. Its converter section has an IP20 protection rating, so the unit must be installed inside a suitable switchgear enclosure to prevent accidental contact and limit exposure to contaminants. The standard hardware configuration retains the factory airflow path, control terminals, and relay assignments. The drive does not include an EMC filter, fieldbus option, or application option card. External components are therefore required when an installation needs additional emission control or network communication, while analog reference signals can be connected directly through the available control terminals.
The slim book-style form factor simplifies side-by-side mounting and preserves space for heat dissipation in crowded control cabinets. A built-in display (SLCP) shows operating frequency, current, and alarm codes for local setup and diagnostics. This display permits direct access to essential operating information without requiring a remote keypad. The internal circuitry uses the standard configuration, and the circuit boards are supplied without a protective coating. Cabinet humidity and airborne contamination must remain within acceptable limits because the exposed circuit boards do not have an added barrier against moisture, chemical vapors, or conductive dust. The lack of an integrated RFI filter or fieldbus board suits installations that use analog references and properly shielded motor leads to meet their control and interference requirements.
