X5C40020C Danfoss
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
The Danfoss X5C40020C is part of the Low Voltage VACON X Drives series and supports a frequency range from 0.1 to 400 Hz with output voltage for 3-phase applications up to the full incoming voltage. Rated at 1 HP for heavy duty and 2 HP for normal duty, it operates within temperatures from -10 to 40 degrees Celsius and tolerates humidity up to 95% non-condensing. The drive handles overload capacities of 150% for heavy duty and 120% for normal duty, with reliable performance up to 1000 meters altitude.
Internal Product Review
The X5C40020C is a Danfoss low-voltage AC drive with a 0.1 to 400 Hz frequency range and 3-phase output voltage up to 100% of incoming voltage. Heavy-duty operation at 1 HP with 150% rated RMS overload capacity gives the drive strong control margin for demanding variable-speed applications. Operating tolerance from -10 °C to +40 °C with 0% to 95% non-condensing humidity makes the drive a strong choice for consistent industrial duty.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The X5C40020C is a low-voltage AC drive manufactured by Danfoss for the Low Voltage VACON X Drives series. It converts fixed-frequency mains power into variable output for motor speed control in conveyors, mixers, and pump stations used in industrial automation. Its rugged housing and decentralized mounting options let the drive sit closer to the load, which can reduce wiring length and save cabinet space.
The inverter covers a frequency span from 0.1 to 400 Hz, giving a broad operating range for both slow and high-speed duties. Heavy-duty service is limited to 1 HP, while normal-duty operation reaches 2 HP, so one frame can support different thermal demands. Compatibility with utility grids at 50/60 Hz ±2 Hz simplifies global deployment, and full performance is maintained up to 1000 m altitude without routine derating.
An ambient window of −10 °C to +40 °C defines continuous operating limits for the drive. The output stage adjusts line voltage across 0 to 100% of incoming voltage, allowing the controller to match motor demand over the commanded speed range. Momentary overload capability reaches 150% of rated RMS current in heavy-duty mode and 120% of rated RMS in normal-duty mode, which helps the drive absorb short load spikes without immediate nuisance trips.
Wake Industrial supplies a 1-year warranty with every unit. Same-day shipping is available when rapid replacement is critical. For questions about fault codes or general specifications, customers can use the chat tool available on the website for quick answers during maintenance planning or troubleshooting tasks.
