The Bosch Rexroth Indramat VT-MSPA 1-525-10-V0 is part of the VT-MSPA Drives series and weighs 0.14 kg. It features a nominal voltage of 24 V, a protection class of IP 20, and uses 12 spring-type terminals for connection. The drive supports a maximum solenoid current of 2.7 A and is made from glass-fiber reinforced polyamide housing.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VT-MSPA 1-525-10-V0 is a low-voltage drive card produced by Bosch Rexroth Indramat for the VT-MSPA Drives series. Installed on a DIN rail inside control cabinets, the module supplies regulated current to proportional solenoids or other 24-volt loads used in industrial automation, allowing repeatable motion or flow control from compact electronic circuitry. By combining an onboard amplifier with spring-type field connectors, it links PLC command signals to the power stage that actuates mechanical components, simplifying the wiring of hydraulic or pneumatic systems.
The board operates from a nominal supply of 24 V, and it tolerates overvoltage conditions up to 36 V; this permits operation on battery-backed or lightly regulated power rails without damage. A peak solenoid drive of 2.7 A is the highest continuous coil current the circuit can deliver, so connected valve coils must keep current within that limit. Command inputs pass through a 100 Ω load, forming a defined burden for voltage sources such as analog cards, while the reference input exhibits a high 200 kΩ resistance that minimizes loading of sensor outputs. Twelve spring-type terminals provide tool-free field wiring, and residual ripple is limited to 2.5 Vpp to maintain stable magnetic force on the actuator.
The module carries an IP 20 rating, which means it has finger-safe openings but no protection against liquids, and it weighs only 0.14 kg, which helps with panel layout. Continuous operation is permitted up to 2000 m installation altitude and through ambient swings of 5 °C per minute, provided that the upstream supply is protected by a 3.15 A time-lag fuse to clear fault currents. The housing is molded from glass-fiber-reinforced polyamide that withstands 15 g shocks lasting 11 ms across three axes, and the output stages remain stable with loads down to 1000 Ω at the terminals.
Frequently Asked Questions about VT-MSPA 1-525-10-V0:
Q: What connection type is provided on the VT-MSPA 1-525-10-V0 drive?
A: The VT-MSPA 1-525-10-V0 uses 12 spring-type terminals for connection.
Q: What is the nominal voltage of the VT-MSPA 1-525-10-V0?
A: This drive has a nominal voltage rating of 24 V.
Q: What is the maximum solenoid current supported by the VT-MSPA 1-525-10-V0?
A: The maximum allowed solenoid current is 2.7 A on this model.
Q: What material is used for the housing of the VT-MSPA 1-525-10-V0?
A: Its housing is made from glass-fiber reinforced polyamide.
Q: What protection class does the VT-MSPA 1-525-10-V0 feature?
A: The VT-MSPA 1-525-10-V0 is rated for protection class IP 20.
