Product Description

The VT-HNC100-1-2X/W-08-I-0 digital axis control provided by Bosch Rexroth works with the WIN-PED software. This control requires data sets for its functioning. The product is capable of offering position-dependent braking. The device has reserved pins on its X1 and X3 connectors. The Windows operating system based computer in which the WIN-PED software is installed must have at least 8MB RAM although 16MB is recommended. The control is fitted with a sandwich plate shut-off valve and a position measuring system. The unit features 1 Ohm load resistance for its analog outputs. It's Logic 0 digital inputs have an input voltage ranging between 0V and 1V.

The product uses flexible conductors with up to 1.5mm² cross-section for the switching inputs and switching outputs. The device is meant to be stored at a temperature ranging from -20°C to 70°C. The voltage supply of the analog inputs/outputs are connected to Pin 12 and Pin 13 of the X2 connector. The unit permits connectivity with an SSI encoder or an incremental encoder with its X3 connector. Its analog outputs have a +/-60mV residual ripple current without noise. This product supports easy parameterizing, programming, editing as well as diagnosis. The control with backup support of one year is sent to your choice of address.

The device output or flag can be set or reset using the M90 and M91 NC commands. The unit supports multiple interfaces for the measuring systems. The WIN-PED software portrays integrated online help documentation that helps in its ease of use. The control has an Inter-Bus bus connection as its field bus system. This bus helps the control to communicate with other higher-level controllers. The features of this product are dependent on the closed loop algorithms that are used. This device is built with a rugged housing that accounts for its durability and stability. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
