VMA 35 BR 001-D
Wake Industrial LLC is not an authorized distributor of this product.
MPN: 1070070785
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The VMA 35 BR 001-D Supply Module is manufactured by Bosch Rexroth. The Supply Voltage is 400-460 VAC. The Current Input for this module is 2.3A and the rated output power is 24 kVA.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Bosch VMA 35 BR 001-D is a power supply module with mains-friendly sinusoidal energy recovery. A VM module with energy recovery is connected to the supplying mains through a mains connection module NA and a line reactor NE. The supply module is designed for use with Servodyn-D systems. The supply voltage for the module is 400 to 460 Volts AC (three-phase). The line frequency range for the voltage supply is 48 to 62 Hertz. Rated current of the VMA 35 BR 001-D is 35 Amps at 45 degrees Celsius. The rated output power is 24 kVA at 45 degrees Celsius. The output power derates between 45 and 55 degrees Celsius at a rate of 0.95 Watts per K. The peak power output of the VMA 35 BR 001-D module is 34.6 kVA. The VMA 35 BR 001-D supply modules draws 2.3 Amps current from the external 24 Volts DC power supply.
The 24 Volts DC supply must conform to the requirements of safety separation. It is particularly important that the requirements of the overvoltage category III are observed. The peak power loss inside the switch cabinet is 460 Watts. Width of the VMA 35 BR 001-D module is 100 millimeters. The weight of the power supply module is approximately 11.1 kilograms. A RMB/VM backplane module is required for the supply module. The VMA 35 BR 001-D is an air cooled device. Adequate amount of spacing should be provided around the installed power supply module so that air can flow freely and the ambient temperature is kept within safe limits. Operation of the module at temperatures that exceed 55 degrees Celsius is not recommended. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
