Product Description:

The VEP40.4EIN-512NN-MAD-1G0-NN-FW is an operator terminal produced by Bosch Rexroth Indramat within the VEP Embedded Terminals series. The unit combines a touch interface with dedicated machine keys and serves as a human-machine interface for drive-based or PLC-based automation cells. By hosting visualization software and presenting process data locally, it allows users to issue commands and monitor machine states without relying on a separate PC. The integrated display and key area make it suitable for mounting close to the machine, where alarms, setpoints, and operating pages need to be available at the point of use.

The terminal operates from 24 V DC and draws up to 1.5 A during steady operation, while an inrush pulse of 7 A for 6 ms must be accommodated at power-up. Average consumption reaches 36 W, which should be considered when sizing the cabinet power supply. Processing resources include 512 MB of RAM and 1 GB of flash storage for application files and recipe data. That onboard memory supports the operating environment as well as locally stored project information. Visualization is shown on a 12.1-inch TFT panel with a resolution of 800 x 600 pixels and 262,144 colors, providing a clear display for process screens. Interaction takes place through the touch panel and 16 hard keys, so the interface supports both screen-based input and direct key commands.

The aluminum front is rated IP65, which helps keep dust and low-pressure water jets away from the display area. The rear electronics section is rated IP20 and is intended for installation inside a protected enclosure. Network communication is handled through one 10/100 Mbps Ethernet port for controller exchange or remote access. Service devices and removable media can connect through two USB 2.0 ports. The available interfaces support controller communication and routine service connections without additional external adapters.
