VDP80.1FKN-C1-NN-EN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911172321
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
29 Seconds
The Bosch Rexroth Indramat VDP80.1FKN-C1-NN-EN is part of the VDP IndraControl Panels series. It offers 24 digital inputs, 16 digital outputs, and supports a supply voltage of 24 V DC. The panel also includes 32 user-changeable keys, four preassigned keys, and a nominal current of 2 Amps.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VDP80.1FKN-C1-NN-EN is an operator interface panel produced by Bosch Rexroth Indramat within the VDP IndraControl Panels series. Intended for cabinet-door mounting, the unit combines push-buttons, labeling areas, and encoder connectivity so that operators can issue commands and monitor machine states locally. In an automation cell, it acts as the human-machine gateway for an IndraDrive or PLC, routing discrete signals from keys, handwheels, and safety circuits directly to the controller without separate terminal blocks. This arrangement keeps essential operator commands close to the machine and supports straightforward local control.
It runs from a 24 V DC supply and draws a nominal panel current of 2 A, while the internal protection limits the total load on the sourcing terminals to 1 A. Discrete field equipment can be wired to the on-board I/O bus, which accepts 24 bits of digital input status and drives 16 bits of digital output. Each sourcing channel is rated for 100 mA, enabling direct actuation of contactors or pilot lamps without external relays. The panel also reserves four emergency-stop pins, four additional handwheel pins, and four changeable labeling strips so the safety chain, manual jog, and legend areas are predefined. A 5 V auxiliary feed powers external handwheel encoders, and four preassigned keys provide immediate access to frequently used machine functions. This combination allows one panel to handle both signal monitoring and local command entry.
Operator customization is extended through 32 user-changeable keys that accept embossed caps, while the hardwired connector offers 25 pins for attaching a manual handwheel without internal rewiring. Paper identifiers can be inserted in accordance with the DIN A4 label strip format, allowing legends to be updated when machine functions change. The panel face can therefore be adapted to different operating layouts while keeping handwheel access and key labeling clear and organized.
Frequently Asked Questions about VDP80.1FKN-C1-NN-EN:
Q: How many digital input bits are available on the VDP80.1FKN-C1-NN-EN panel?
A: This device features 24-bit digital inputs for connecting a variety of discrete signals.
Q: How many user-changeable keys does the VDP80.1FKN-C1-NN-EN panel offer?
A: The VDP80.1FKN-C1-NN-EN supports 32 user-changeable keys, enabling flexible customization of panel controls.
Q: What is the supply voltage for the VDP80.1FKN-C1-NN-EN controller panel?
A: The supply voltage required for operation is 24 V DC.
Q: How many digital output bits are present on the VDP80.1FKN-C1-NN-EN?
A: This model provides 16 bits for digital outputs, suitable for controlling multiple external devices.
Q: How many pins are included on the handwheel connector of the VDP80.1FKN-C1-NN-EN?
A: The handwheel connector on this panel comes with a total of 25 pins for interface.
