VDP40.2DFN-G5-PS-NN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911171588
Ask for AvailabilityThe Bosch Rexroth Indramat VDP40.2DFN-G5-PS-NN is part of the VDP IndraControl Panels series and has a 15 inch TFT display with a resolution of 1024 x 768 pixels and 256,000 colors. This panel features touch and keyboard input, 16 M-Keys, 5 USB ports, and a maximum power draw of 36 Watts. It offers IP65 front protection, a backlight life of 50,000 hours, and weighs 5.8 kilograms.
Internal Product Review
The VDP40.2DFN-G5-PS-NN is an IndraControl panel with a TFT display and touch-plus-keyboard input for efficient machine interaction. IP65 front protection and 16 M-Keys give this unit dependable usability in demanding industrial settings. The 1024 x 768 resolution makes this panel a strong choice for clear and consistent process visualization.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VDP40.2DFN-G5-PS-NN panel belongs to the VDP IndraControl Panels series manufactured by Bosch Rexroth Indramat. It is an operator interface unit for industrial automation systems, combining a TFT display with a sealed front panel so machine status, recipes, and alarms can be entered or acknowledged directly at the machine. This layout supports local control and clear process visualization without requiring a separate external interface station.
The viewing area measures 381 mm (15"), and graphics are rendered at 1024 × 768 px, allowing clear visualization of process data. Color depth reaches 256,000 colors, which helps distinguish operating states on complex HMI layouts. The front face carries a rating of IP65, which means it is protected against dust and low-pressure water jets when mounted from the front of the cabinet. Maximum power draw is limited to 36 W, so standard 24 V DC control-cabinet supplies can power the unit without additional conditioning. The G5 interface supports a single-cable connection to compatible Rexroth controller families, and the touch-and-keyboard input method lets the operator select on-screen objects or issue fixed commands. Five USB ports are available, and each port can supply up to 500 mA for connected peripherals.
Service life is supported by a backlight rated for 50000 h, which helps reduce the frequency of display-related maintenance. Sixteen programmable function keys, listed as 16 M-Keys, provide direct access to frequently used machine cycles. Cabinet integration is simplified by a mounting depth of 68.4 mm, and once installed in the cutout, the panel presents a front surface measuring 407 mm in width by 370 mm in height. Total mass is only 5.8 kg, which helps simplify handling during installation. Its shallow profile also suits enclosure layouts where front-panel space is available but internal depth is limited.
