VDP40.2BIN-G4-PS-NN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911309426
The Bosch Rexroth Indramat VDP40.2BIN-G4-PS-NN is part of the VDP IndraControl Panels series and features a 15 inch display with a resolution of 1024 x 768 pixels and color depth of 256,000 colors. The panel includes 16 machine function keys, has front panel protection rated at IP65, and operates on a 24 V DC supply voltage. Maximum current consumption is 2 A, and it can operate at temperatures between 5 °C and 45 °C.
Internal Product Review
The VDP40.2BIN-G4-PS-NN is an IndraControl panel designed for key operation with 16 machine function keys. A 15-inch display and 1024 x 768 resolution give the interface clear, precise visualization for machine-level control. IP65 front panel protection makes this model especially well suited for demanding industrial environments.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VDP40.2BIN-G4-PS-NN is an operator panel produced by Bosch Rexroth Indramat and belongs to the VDP IndraControl Panels series. It serves as a human-machine interface for programmable logic controllers, giving plant personnel direct access to motion, process, and diagnostic data through a combination of a TFT screen and membrane keys. The interface supports routine status viewing, alarm acknowledgment, and menu navigation during normal machine operation. By integrating display and hardened keypad functions in one housing, the unit simplifies cabinet layouts and shortens wiring runs inside automated assembly cells, packaging machines, and material-handling stations.
The panel renders graphics with 256,000 colors, allowing distinct alarm palettes and detailed equipment schematics. A diagonal size of 381 mm (15") offers a readable workspace for multi-window SCADA layouts, while its native resolution of 1024 × 768 px supports vector-based objects without scaling artifacts. Electrical integration is straightforward because the electronics operate from a 24 V DC control circuit and draw no more than 2 A. Sixteen dedicated machine function keys sit below the display so operators can trigger frequent commands without navigating soft menus, which helps reduce interruptions during repetitive tasks.
The aluminum front complies with IP65, so airborne coolant or dust cannot enter when the panel is flush mounted. Internally mounted components endure industrial knocks up to 15 g, and reliable touch response is maintained from +5 °C to a ceiling of +45 °C even when ambient temperature changes as fast as 3 K per minute. Installations at elevations up to 2000 m above sea level are supported without derating, aided by passive convection through the 68.4 mm mounting depth. With an overall footprint of 370 mm in height and 407 mm in width, the unit fits standard 19-inch panel cutouts while leaving clearance for rear-side I/O cabling.
