The Bosch Rexroth Indramat VDP21.3CNN-D1-NN-C5 is part of the VDP IndraControl Panels series and features a 546 mm diagonal TFT display with a resolution of 1920 x 1080 pixels and 16.7 million colors. Its stainless steel housing measures 552 by 348 by 56 mm, comes with a multi-touch screen made from thermally tempered glass, and is rated IP65 at the front and IP20 at the rear. The panel operates on a 24 V DC supply voltage and has two USB host ports.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VDP21.3CNN-D1-NN-C5 panel is produced by Bosch Rexroth Indramat and belongs to the VDP IndraControl Panels series. It functions as an operator interface in industrial automation, linking machine controls to operators through an integrated screen and touch input layer. By mounting on the machine front or cabinet door, it consolidates visualization, command entry, and status feedback for motion controllers, drives, or PLC systems. This arrangement allows the unit to present process information and accept user input from the same front-mounted interface.
The panel integrates a TFT display with a diagonal of 546 mm, delivering a native resolution of 1920 × 1080 px. Images are rendered in 16.7 million colors, allowing clear differentiation of process states and alarm icons. The active visual range of 478 × 270 mm matches the bezel geometry, and optical bonding to the front thermally tempered glass helps limit reflections. Input power is supplied at 24 V DC through a 3-pin MC1,5/3-G-3,5 THT connector, while control data is exchanged over the dedicated CDI panel interface, keeping video and USB traffic on a single hybrid cable. The full HD display format supports detailed operating screens with clearly separated text, graphics, and status fields.
Environmental resilience is provided by a front rating of IP65 when the unit is panel-mounted, sealing the tempered glass and stainless-steel bezel against dust and low-pressure water jets. The rear zone remains at IP20, which suits installation inside protected enclosures. A projected-capacitive interface supports multi-touch gestures for zoom functions or two-hand safety acknowledgments, and two integrated USB host ports allow quick log retrieval or barcode reader hookup; the port count is 2. The panel occupies a housing footprint of 552 × 348 × 56 mm and requires a 535 × 330 mm cutout in the machine door, with stainless-steel construction certified for Zone A, B, and C hygiene classes. This front-and-rear protection arrangement fits applications where the operator side is exposed while the back of the unit remains inside the cabinet.
Frequently Asked Questions about VDP21.3CNN-D1-NN-C5:
Q: What is the screen resolution of the VDP21.3CNN-D1-NN-C5 panel?
A: The display on the VDP21.3CNN-D1-NN-C5 has a resolution of 1920 x 1080 pixels for detailed image clarity.
Q: What type of touch interface does the VDP21.3CNN-D1-NN-C5 panel use?
A: This model features a multi-touch input system for flexible and intuitive operation.
Q: How many USB host ports are available on the VDP21.3CNN-D1-NN-C5?
A: The VDP21.3CNN-D1-NN-C5 is equipped with two USB host ports for external device connections.
Q: What level of front protection does the VDP21.3CNN-D1-NN-C5 offer?
A: Front protection of IP65 ensures the panel is resistant to dust and low-pressure water jets from the front.
Q: What material is used for the front surface of the VDP21.3CNN-D1-NN-C5?
A: The panel's front surface is made of thermally tempered glass for enhanced durability.
