VDP16.2BKN-G4-PS-NN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911309425
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
13 Seconds
The Bosch Rexroth Indramat VDP16.2BKN-G4-PS-NN is part of the VDP IndraControl Panels series and features a 12 inch TFT display with a resolution of 800 x 600 pixels and support for 256,000 colors. It comes with a G4 display interface, 16 machine keys, and a foil keyboard for operation. This panel offers front protection rated at IP65, includes 5 USB ports, and operates at 24 V DC with a maximum power draw of 24 watts.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The VDP16.2BKN-G4-PS-NN operator panel is produced by Bosch Rexroth Indramat within the VDP IndraControl Panels series. It functions as a compact human-machine interface for industrial automation, allowing operators to call up screens and issue commands directly at the machine. By combining visualization, soft keys, and power electronics in one front-mountable enclosure, the panel reduces cabinet depth and simplifies local diagnostics. This arrangement keeps status display and command entry close to the controlled process during routine operation. Because the controls and display are integrated into the same panel, routine status checks can be performed without moving to a separate cabinet-mounted interface.
It presents data on a 304.8 mm (12 in) diagonal TFT screen that supports 256,000 colors for multistate graphics. The display has a resolution of 800 x 600 px, so process diagrams remain legible from common operating distances. This format supports clear menu pages, alarm screens, and machine-status views without requiring an oversized front panel. Communication with the controller is handled through the G4 interface, which is a high-speed link dedicated to the VDP family. Electrically, the panel accepts 24 V DC supply and draws up to 2 A, permitting connection to standard 24-volt power rails without a separate converter. The foil keyboard uses elastomer domes beneath the overlay to provide uniform tactile response and long actuation life during shift operation.
The housing provides IP65 front protection so sprayed coolant or airborne dust cannot reach the electronics. The sealed front also suits installations where the panel is exposed to dust, splash, and routine wipe-down of the machine face. Sixteen machine keys sit below the display, and each key is shaped for gloved operation and mapped in the PLC for direct function calls. For removable media and service devices, the panel offers 5 USB host ports, each limited to a per-port current of 500 mA. Overall consumption peaks at 24 W, which helps keep thermal load low even when the backlight and ports are active. Mounting dimensions measure 350 mm in width and 290 mm in height, while the assembly weight is 4.0 kg, allowing installation on swing arms or pendant brackets without excessive support hardware.
Frequently Asked Questions about VDP16.2BKN-G4-PS-NN:
Q: What is the display size and type of the VDP16.2BKN-G4-PS-NN panel?
A: The VDP16.2BKN-G4-PS-NN features a 12-inch TFT display for clear image representation.
Q: How many colors can the VDP16.2BKN-G4-PS-NN panel display?
A: This panel supports up to 256,000 colors for vibrant graphical outputs.
Q: What type of input interface and how many machine keys does the VDP16.2BKN-G4-PS-NN have?
A: The VDP16.2BKN-G4-PS-NN features 16 machine keys and uses a foil keyboard for operation.
Q: What is the level of front protection offered by the VDP16.2BKN-G4-PS-NN panel?
A: This model is protected with an IP65 rating on the front, providing resistance against dust and water jets.
Q: How many USB ports does the VDP16.2BKN-G4-PS-NN include, and what is the maximum current per port?
A: Equipped with 5 USB ports, each port supports a maximum current of 500 mA.
