Product Description:

The VDP15.3GAN-D1-NN-CH operator terminal is produced by Bosch Rexroth Indramat as part of the VDP IndraControl Panels series. It serves as a human-machine interface that combines visualization, parameter entry, and alarm acknowledgment for automated machinery. Intended for cabinet or arm mounting, the panel relays commands and status information between PLCs and operators, allowing local recipe changes and diagnostics without a separate PC. Fanless construction and a low-voltage DC supply support placement near drives and motors while keeping emitted electrical noise to a minimum.

The front surface is dominated by a TFT screen that measures 39.6 cm (15.6"); this diagonal gives operators a wide workspace for trend graphs and status tiles. Its native resolution of 1366 x 768 pixels pairs with a color depth of 16 million colors, so gradients and small icons remain legible even in complex SCADA pages. Input is accepted through a Multi-Touch sensor, enabling two-finger zooming or gesture navigation rather than single-point presses. Electrical integration is simple because the unit runs from a 24 V DC supply and draws only 24 W, keeping cabinet heat dissipation low. Two USB ports accommodate service keyboards or memory sticks, while a single CDI serial link provides high-speed communication to IndraControl controllers. The housing spans 422 mm in width, 275 mm in height, and only 56.5 mm in depth, so the panel projects minimally into the cabinet interior.

For plant environments that include coolant spray and airborne dust, the aluminum front bezel carries an ingress rating of IP65, allowing cleaning with low-pressure water jets. The rear enclosure remains at IP20, which is adequate once the panel is sealed into a cabinet cutout. Mechanical endurance is confirmed by a shock tolerance of 15 g and a vibration limit of 1 g, letting the display operate on moving gantries or near stamping presses. Despite the tempered glass overlay and metal frame, total mass is only 4.8 kg, so swivel arms and height-adjustable mounts require little counterbalance.
